Tern GSD S10 LX 2023
2023 E-bike
Estimate price |
5,399$
Weight | 33.58 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 20" -
Travel Front 70mm -
Fork Suntour
-
Groupset Deore -
Suspension Hardtail -
Motor Bosch 85Nm mid-drive -
Battery Bosch Dual Battery system, 500 Wh/1000 Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tern GSD, 6061-AL, patented MultiTruss design, EFBE Tri-Test approved: 200 kg
Suspension Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE approved: 200 kg
Drivetrain
Rear Derailleur
Shimano Deore Shadow+
Shift Levers
Shimano Deore, 1 x 10 spd
Cassette
Shimano 11-42T, 10 spd
Crank
Tern GSD custom, forged 6061-AL DH crankarm
Bottom Bracket
Motor integrated
Chain
10 spd, DHT for eBike, GST corrosion resistant coating
Chain Guide
Tern Custom, full chain cover
Pedals
Urban with non-slip surface, sealed bearings
Wheels
Front Hub
Tern Atlas, Boost Thru-Axle, Cargo-optimized design, sealed cartridge bearing
Rear Hub
Tern Atlas, Boost Thru-Axle, Syntace X-12 standard, Cargo-optimized design
Rims
Tern Atlas, ultra wide 36 mm, dual reinforced joint
Tires
F: Schwalbe Big Ben Plus, 55-406, Green Guard puncture protection, Reflex R: Tern x Schwalbe Super Moto-X, 62-406, Green Guard puncture protection, Reflex
Brakes
Brakes
Hydraulic Disc
Brake Levers
Magura MT5 e-stop, hydraulic, with brake sensor
Cockpit
Stem
Tern Andros, adjustable, forged construction, patented technology
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Headset
Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated
Seat
Saddle
Tern GSD by Velo, with rear handle
Seatpost
Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm
Motor & Battery
Motor
Bosch Cargo Line, 400% Assist, 85 Nm Torque, max speed 25 kph (EU); max speed 20 mph (US)
Battery
Bosch Dual Battery system, 500 Wh/1000 Wh
About this model
GSD S10 LX completes the Tern E Gsd model. There are 16 e-bikes that carry this model name. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Tern GSD S10 2023 is the most economical model, with a starting price of 4999$. Tern GSD R14 2023 on the other hand costs 7999$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Long Tail Cargo e-bikes
Our math shows that the average cost of a dependable Long Tail Cargo e-bike is 3082$. However, even though the average price of a Long Tail Cargo e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5399$. Doing a quick comparison, we notice that GSD S10 LX price is 75.18% more expensive than the average cost of a Long Tail Cargo e-bike.
Average weight for Long Tail Cargo e-bikes
The average weight for Long Tail Cargo e-bikes is 32.16 kg (70.9 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
GSD S10 LX weighs 33.58 kg (74.03 lbs) and is slightly heavier than the average. In conclusion, the average Long Tail Cargo e-bike weighs 4.42% less than GSD S10 LX.
Overview of components
Fork
Tern GSD S10 LX 2023 e-bike is equipped with the Suntour fork, and has 70mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this e-bike is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
As for the wheels, Tern GSD S10 LX 2023, has a 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
This e-bike has one size only, so it might not fit you. In conclusion, double-check its size to make sure it’s a good fit for you.
