Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 20" -
Travel Front 70mm -
Fork Suntour
-
Groupset XT -
Suspension Hardtail -
Motor Bosch 250W 65Nm mid-drive -
Battery Bosch PowerPack 500 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tern HSD, 6061-AL, patented design, EFBE Tri-Test approved: 170 kg
Suspension Fork
Suntour custom for Tern, 1.5" tapered Chromoly steerer, 32 mm stanchions, Thru-axle, 70 mm travel, EFBE Tri-Test approved: 170 kg
Drivetrain
Shift Levers
Shimano Deore XT, 1 x 11 spd
Cassette
11-36T, 11 spd
Crank
Tern HSD custom
Bottom Bracket
Motor integrated
Chain
KMC 11 spd, EPT corrosion resistant coating
Pedals
Urban with non-slip surface, sealed bearings
Wheels
Front Hub
Novatec, Thru-axle, sealed bearings
Rear Hub
Novatec, sealed cartridge bearing, disc
Rims
Tern Atlas H, wide 35 mm
Tires
Schwalbe Big Ben, 55-406, RaceGuard puncture protection, ECE-R75 ebike certification
Brakes
Brakes
hydraulicDisc
Brake Levers
Magura, hydraulic
Cockpit
Stem
Tern Andros, adjustable, forged construction, patented technology
Handlebar
Tern Sweep, 6061-AL, Tern Andros adapted
Headset
Tern Flux Pro Taper, 1.5", angular contact bearings, Physis integrated
Seat
Saddle
Tern HSD
Seatpost
Cane Creek Thudbuster G4, Tern Telescope, 34.9/30.9 mm
Motor & Battery
Motor
Bosch Performance Sport, 300% Assist, 65 Nm Torque, max speed 28 mph (US)
Battery
Bosch PowerPack 500
About this model
HSD S11 is part of the Tern E Hsd model. Tern launched 20 e-bikes of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Tern HSD P9 2022 is the most economical model, with a starting price of 3699$. Tern HSD S+ 2022 on the other hand costs 6370$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Utility e-bikes
According to our math, the average price for a trustworthy Utility e-bike is 3636$. However, even though the average price of an Utility e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4699$. Doing a quick comparison, we notice that HSD S11 price is 29.24% more expensive than the average cost of an Utility e-bike.
HSD S11 components
Fork
The Suntour is included from the factory. It has a travel distance of 70mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
As for the wheels, Tern HSD S11 2022, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Nothing is more important on a bike than its ability to brake properly. Tern HSD S11 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike has one size only, so it might not fit you. In conclusion, make sure it fits you, or look for another model.
