Transition PATROL Complete Kit 3 2017
2017 Mountain
Estimate price |
4,099$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Wheels 27.5" -
Travel Front 160mm -
Fork RockShox Lyrik
-
Groupset GX, Race Face -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
MD
164cm - 182cm
LG
175cm - 190cm
XL
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox Lyrik RC Solo Air 160mm (Color Match Fork Decals Included)
Rear Shock
RockShox Super Deluxe RC3
Drivetrain
Rear Derailleur
SRAM GX
Shift Levers
SRAM GX
Cassette
SRAM XG1150 (10-42)
Crank
RaceFace Aeffect Cinch (DM32t, 170mm or 175mm)**
Chain
SRAM PC1130
Wheels
Front Hub
SRAM MTH 716/746
Rear Hub
SRAM MTH 716/746
Rims
RaceFace AR 30mm 27.5 32h
Tires
Maxxis Minion DHF 27.5x2.3 EXO Dual Front, Maxxis Minion DHR II 27.5x2.3 EXO Dual Rear
Brakes
Brakes
SRAM Guide R
Disk Rotors
SRAM Centerline (180mm)
Cockpit
Stem
RaceFace Aeffect 35 50mm
Handlebar
RaceFace Chester 35 (780mm x 35mm)
Grips
Velo Single Clamp
Headset
FSA No.57E
Seat
Saddle
ANVL Forge Stealth CroMo
Seatpost
KS Lev Integra w/ Southpaw Remote (150mm, 125mm or 100mm)**
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.4 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 721 mm | 751 mm | 780 mm | 810 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 119 mm | 119 mm | 119 mm | 119 mm |
| Stack | 584 mm | 593 mm | 602 mm | 611 mm |
| Reach | 399 mm | 425 mm | 450 mm | 476 mm |
| Top Tube Length | 548 mm | 576 mm | 606 mm | 634 mm |
| Seat Tube Angle | 76 ° | 75.4 ° | 74.9 ° | 74.5 ° |
| Seat Tube Length | 393 mm | 419 mm | 457 mm | 495 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 423 mm | 423 mm | 423 mm | 423 mm |
| Wheelbase | 1144 mm | 1174 mm | 1203 mm | 1233 mm |
| Bottom Bracket Drop | 15 mm | 15 mm | 15 mm | 15 mm |
| Standover Height | 678 mm | 686 mm | 698 mm | 710 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 164 cm | 175 cm | 184 cm |
| Rider Max Height | 170 cm | 182 cm | 190 cm | 200 cm |
Model Overview
PATROL Complete Kit 3 is part of the Transition Patrol model. There are 56 bikes that carry this model name. Take a sneak peek at all Transition Patrol bikes models from 2017, by clicking here.
Model range prices
Transition PATROL Complete 2017 is the cheapest bike model and costs 3099$. Transition PATROL CARBON Complete Kit 1 2017 is the most expensive one and costs 8999$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Enduro bikes average price
If you want to purchase a solid Enduro bike, it is important to know that the average cost is 3599$. However, even if your budget is less than the average, you might still be able to get a top-quality Enduro bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Transition released this model in 2017, its price was 4099$. Doing a quick comparison, we notice that PATROL Complete Kit 3 price is 13.89% more expensive than the average cost of an Enduro bike.
PATROL Complete Kit 3 components
Fork
The fork installed on this bike is the RockShox Lyrik model. The travel on this model is 160mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels
The PATROL Complete Kit 3 2017 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The PATROL Complete Kit 3 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
PATROL Complete Kit 3 comes in 4 sizes, that range from 154 cm – 200 cm (5.05 ft – 6.56 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
A dropper post is included with the PATROL Complete Kit 3. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
