Transition Repeater GX 2022
2022 E-bike
Estimate price |
9,499$
Weight | 22.3 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 160mm -
Travel Rear 160mm -
Fork RockShox ZEB Ultimate
-
Groupset GX Eagle, Shimano -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Shimano BT-E8036 (630Wh) -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
MD
164cm - 182cm
LG
175cm - 190cm
XL
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Repeater Carbon 160mm
Suspension Fork
RockShox ZEB Ultimate, 160mm, 44mm Offset, 1.8 taper
Rear Shock
Fox Float X Performance Elite, (205x65mm)
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle Single Click
Cassette
SRAM XG 1275 (10-52t)
Crank
Shimano EM900, (34t/160mm)
Chain
SRAM GX Eagle
Chain Guide
OneUp STEPS
Wheels
Front Hub
DT Swiss Hybrid 370
Rear Hub
DT Swiss Hybrid 370
Rims
DT Swiss Hybrid H 1900
Spokes
DT Swiss Hybrid 1
Tires
Front: Schwalbe Magic Mary, Super Gravity, Ultra Soft (29x2.4), Rear: Schwalbe Big Betty, Super Gravity, Soft (29x2.4)
Brakes
Brakes
Magura MT7 w/ HC1 Levers
Disk Rotors
Magura MDR-C (203mm)
Cockpit
Stem
ANVL Swage (40mm)
Handlebar
ANVL Mandrel Alloy, SM (800x20) MD/LG (800x30) XL (800x40)
Grips
ODI Elite Flow Lock-On
Headset
Acros ICR
Seat
Saddle
ANVL Forge Cromo
Seatpost
OneUp Dropper Post, SM (150mm), MD (180mm), LG/XL (210mm)
Motor & Battery
Motor
Shimano DU-EP800
Battery
Shimano BT-E8036 (630Wh)
Remote
Shimano SC-EM800
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.39 mm | 1.34 mm | 1.28 mm |
| Bottom Bracket Height | 340 mm | 340 mm | 340 mm | 340 mm |
| Front Center | 768 mm | 798 mm | 827 mm | 862 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 134 mm | 134 mm | 134 mm | 134 mm |
| Stack | 623 mm | 623 mm | 632 mm | 641 mm |
| Reach | 417 mm | 447 mm | 472 mm | 502 mm |
| Top Tube Length | 551 mm | 581 mm | 609 mm | 642 mm |
| Seat Tube Angle | 78.4 ° | 77.9 ° | 77.4 ° | 77.1 ° |
| Seat Tube Length | 375 mm | 400 mm | 440 mm | 470 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 447 mm | 447 mm | 447 mm | 447 mm |
| Wheelbase | 1213 mm | 1243 mm | 1272 mm | 1307 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 697 mm | 707 mm | 712 mm | 717 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 164 cm | 175 cm | 184 cm |
| Rider Max Height | 170 cm | 182 cm | 190 cm | 200 cm |
Model Overview
Repeater GX is part of the Transition E Repeater model. There are 8 e-bikes that carry this model name. Take a sneak peek at all Transition E Repeater e-bikes models from 2022, by clicking here.
Model range prices
Transition Repeater NX 2022 is the most affordable e-bike of this model and has a price of 8199$. On the other hand, Transition Repeater AXS 2022, is the most expensive and costs 10999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Enduro e-bikes
According to our math, the average price for a trustworthy Enduro e-bike is 4785$. However, you could also get a good Enduro e-bike even if you pay a lower amount than the average price. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Transition Repeater GX price was 9499$. Comparing the average cost of an Enduro e-bike to this one, you will see that Repeater GX price is 98.52% higher.
Enduro e-bikes average weight
On a deeper look, we notice that the average weight of an Enduro e-bike is 23.42 kg (51.63 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 22.3 kg (49.16 lbs), the Repeater GX model is a bit lighter than average. In other words, this model is 5.02% lighter than the average Enduro e-bike.
Overview of components
Fork
The Repeater GX comes factory-installed with the RockShox ZEB Ultimate fork. This has a travel range of 160mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Transition Repeater GX e-bike has the Fox Float X Performance Elite model installed, and has a travel of 160mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
As for the wheels, Transition Repeater GX 2022, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Nothing is more important on a bike than its ability to brake properly. Transition Repeater GX is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 200 cm (5.05 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Transition model is also equipped with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
