Trek Allant+ 7 2021
2021 E-bike
Estimate price |
3,599$
Weight | 24.49 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 45mm -
Fork SunTour MOBIE
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 500 -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
165cm - 176cm
LG
174cm - 187cm
XL
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High-performance hydroformed alloy, Removable Integrated Battery, Range Boost-compatible, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Suspension Fork
Size: M, L, XL, SR Suntour Mobie25, 45mm travel, preload, rebound and lockout, tapered alloy steerer, post mount disc; Size: M, L, XL, SR Suntour Mobie25, coil spring, tapered alloy steerer, preload, rebound, lockout, post mount disc, 100x15mm thru-axle, 50mm travel
Drivetrain
Rear Derailleur
Shimano Alivio T4000, long cage
Shift Levers
Size: M, L, XL, Shimano Alivio M3100, 9 speed; Size: M, L, XL, Shimano Alivio M4000, 9 speed
Cassette
Shimano HG200, 11-36, 9 speed
Crank
Size: M, ProWheel alloy, 170mm; Size: L, XL, ProWheel alloy, 175mm
Chain
KMC E9S, 9 speed
Wheels
Front Hub
Bontrager Disc, 32-hole, 6-bolt disc, 15mm alloy thru-axle
Rear Hub
Bontrager alloy, sealed bearing, 6-bolt, 135x5mm QR
Rims
Alex MD35, tubeless compatible, 32-hole, 35mm width, presta valve
Spokes
Size: M, L, XL, J-Bend, 14g, Steel, Black; Size: M, L, XL, DT Swiss 14g, black
Tires
Schwalbe G-One, 650Bx57c
Brakes
Brakes
Shimano MT200 hydraulic disc
Disk Rotors
Shimano RT26, 6-bolt,180mm
Cockpit
Stem
Size: M, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: L, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: XL, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: XL, Bontrager alloy, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length
Handlebar
Size: M, Bontrager alloy, 31.8mm, 15mm rise, 600mm width; Size: L, XL, Bontrager alloy, 31.8mm, 15mm rise, 660mm width
Grips
Bontrager Satellite Elite, alloy lock-on
Headset
Size: M, L, XL, FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom; Size: M, L, XL, FSA IS-2 alloy, integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Commuter Comp
Seatpost
Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 330mm length
Motor & Battery
Motor
Bosch Performance CX, magnesium motor body, 250 watt, 85 Nm, 20mph or 32km/h max assist
Battery
Bosch PowerTube 500
Charger
Bosch standard 4A (100-240V) charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.55 mm | 1.61 mm | 1.68 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 665 mm | 669 mm | 683 mm |
| Rake | 44 mm | 41 mm | 44 mm |
| Trail | 86 mm | 81 mm | 79 mm |
| Stack | 618 mm | 647 mm | 683 mm |
| Reach | 400 mm | 403 mm | 407 mm |
| Top Tube Length | 590 mm | 602 mm | 617 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 446 mm | 491 mm | 534 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70.5 ° |
| Head Tube Length | 165 mm | 195 mm | 230 mm |
| Chainstay Length | 482 mm | 482 mm | 482 mm |
| Wheelbase | 1141 mm | 1145 mm | 1159 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 790 mm | 832 mm | 874 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 165 cm | 174 cm | 185 cm |
| Rider Max Height | 176 cm | 187 cm | 197 cm |
About this model
Allant+ 7 belongs to the Trek E Allantplus model. Trek released 60 e-bikes variations of this model so far. You can easily view all of the Trek E Allantplus e-bikes models from 2021, here.
Model range prices
The most economical model, the Trek Allant+ 7 Lowstep 2021 has a starting price of 3599$. Trek Allant+ 9.9 Stagger 2021 on the other hand is the most expensive at 7113$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Trek Allant+ 7 price was 3599$. If we compare this with the average Commuter e-bike cost we notice that the price is 40.09% more expensive.
Commuter e-bikes average weight
The average weight for Commuter e-bikes is 25.2 kg (55.56 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Allant+ 7 weighs 24.49 kg (53.99 lbs) and is slightly lighter than the average. In short, the average Commuter e-bike weight is 2.9% higher than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Allant+ 7 comes factory-installed with the SunTour MOBIE fork. This has a travel range of 45mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
The fork on this e-bike is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels
When it comes to wheels, the Allant+ 7 e-bike is equipped with the aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 3 sizes. They vary from 165 cm – 197 cm (5.41 ft – 6.46 ft). In conclusion, it won’t take much to find one that’s right for you.
