Trek Allant+ 8S Stagger 2023
2023 E-bike
Estimate price |
3,999$
Weight | 25.58 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset Deore -
Suspension Rigid -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch PowerTube 625Wh -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High-performance hydroformed alloy, Removable Integrated Battery, Range Boost-compatible, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Suspension Fork
Allant+ rigid alloy fork, 1-1/8'' steel steerer, 100x15mm thru axle, post mount disc brake
Drivetrain
Rear Derailleur
Size: S, M, L, Shimano Deore M5120, long cage; Size: S, M, L, Shimano Deore M6000, mid cage, 42T max cog
Shift Levers
Shimano Deore M4100, 10 speed
Cassette
Size: S, M, L, Shimano Deore M4100, 11-42, 10 speed; Size: S, M, L, Shimano HG500, 10 speed
Crank
Size: S, M, ProWheel alloy, 170mm length; Size: L, ProWheel alloy, 175mm length
Chain
Size: S, M, L, KMC E10; Size: S, M, L, KMC X10e
Pedals
Size: S, M, L, Bontrager City pedals; Size: S, M, L, Wellgo C157, boron axle, plastic body; Size: S, M, L, slip-proof aluminum pedals with reflectors
Wheels
Front Hub
Bontrager sealed bearing, 32-hole 15mm alloy thru-axle
Rear Hub
Bontrager alloy, sealed bearing, 6-bolt, 135x5mm QR
Rims
Alex MD35, tubeless compatible, 32-hole, 35mm width, Presta valve
Spokes
Size: S, M, L, 14g stainless steel, black; Size: S, M, L, 14g stainless
Tires
Bontrager E6 Hard-Case Lite, reflective strip, 27.5x2.40''
Brakes
Brakes
Shimano MT520 4-piston hydraulic disc, post-mount, 180mm rotor
Cockpit
Stem
Size: S, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: M, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: L, Bontrager alloy, 31.8mm, Blendr compatible, 7 degree, 90mm length
Handlebar
Size: S, M, Bontrager alloy, 31.8mm, 15mm rise, 600mm width; Size: L, Bontrager alloy, 31.8mm, 15mm rise, 660mm width
Grips
Bontrager Satellite Elite, alloy lock-on
Headset
Size: S, M, L, FSA IS-2 alloy, integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom; Size: S, M, L, FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Commuter Comp
Seatpost
Bontrager Comp, 6061 alloy, 31.6mm, 8mm offset, 330mm length
Motor & Battery
Motor
Bosch Performance Speed, 85 Nm, 28 mph / 45 kph
Battery
Bosch PowerTube 625Wh
Charger
Bosch standard 4A, 100-240V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.53 mm | 1.6 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm |
| Front Center | 658 mm | 661 mm | 673 mm |
| Rake | 44 mm | 41 mm | 44 mm |
| Trail | 89 mm | 84 mm | 82 mm |
| Stack | 596 mm | 620 mm | 652 mm |
| Reach | 401 mm | 404 mm | 407 mm |
| Top Tube Length | 583 mm | 594 mm | 607 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 450 mm | 491 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° |
| Head Tube Length | 140 mm | 165 mm | 195 mm |
| Chainstay Length | 486 mm | 486 mm | 486 mm |
| Wheelbase | 1138 mm | 1141 mm | 1153 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 705 mm | 709 mm | 755 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 155 cm | 164 cm | 174 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm |
About this model
Allant+ 8S Stagger is part of the Trek E Allantplus model. 60 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
The most economical model, the Trek Allant+ 7 Lowstep 2023 has a starting price of 3499$. Trek Allant+ 9S Stagger 2023 on the other hand is the most expensive at 5626$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Commuter e-bikes
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
At the moment of the release date, Trek Allant+ 8S Stagger price was 3999$. If we compare this with the average Commuter e-bike cost we notice that the price is 55.66% higher.
Commuter e-bikes average weight
The average weight for Commuter e-bikes is 25.2 kg (55.56 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
With a weight of 25.58 kg (56.39 lbs), Trek e-bike is slightly heavier than average. In conclusion, the average Commuter e-bike weighs 1.51% less than Allant+ 8S Stagger.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Allant+ 8S Stagger components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
As for the wheels, Trek Allant+ 8S Stagger 2023, has a aluminum model. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Trek Allant+ 8S Stagger e-bike has 3 sizes, in the range of 155 cm – 186 cm (5.09 ft – 6.1 ft). In conclusion, it won’t take much to find one that’s right for you.
