Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork SunTour NEX
-
Groupset Alivio, Acera -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminum, DuoTrap S compatible, rack & fender mounts
Suspension Fork
SR Suntour NEX, coil spring, preload, hydraulic lockout, 63mm travel
Drivetrain
Rear Derailleur
Shimano Alivio T4000
Front Derailleur
Shimano Acera
Shift Levers
Shimano Acera M3000, 9 speed
Cassette
Shimano HG20, 11-34, 9 speed
Crank
Shimano Acera M371, 48/36/26 w/chainguard
Bottom Bracket
Sealed cartridge
Chain
KMC X9
Pedals
Resin body, alloy cage
Wheels
Front Hub
Formula DC20 alloy
Rear Hub
Formula DC22 alloy
Rims
Bontrager Tubeless Ready Disc, 32h
Tires
Bontrager LT2, Hard-Case Lite, 700x38c
Brakes
Brakes
Shimano M315 hydraulic disc
Cockpit
Stem
Bontrager Elite, 31.8mm, 7 degree, w/computer & light mounts
Handlebar
Bontrager alloy, 31.8mm, 15mm rise
Grips
Bontrager Satellite Elite, lock-on, ergonomic
Headset
1-1/8? threadless, sealed cartridge bearings
Seat
Saddle
Bontrager H1
Seatpost
Bontrager, 2-bolt head, 27.2mm, 8mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19" | 21" | 22.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.451 mm | 1.457 mm | 1.456 mm | 1.465 mm | 1.472 mm |
| Bottom Bracket Height | 294 mm | 294 mm | 294 mm | 294 mm | 294 mm |
| Front Center | 643 mm | 647 mm | 657 mm | 662 mm | 664 mm |
| Rake | 33 mm | 38 mm | 37 mm | 39 mm | 37 mm |
| Trail | 85 mm | 82 mm | 82 mm | 78 mm | 75 mm |
| Stack | 595 mm | 606 mm | 616 mm | 627 mm | 639 mm |
| Reach | 410 mm | 416 mm | 423 mm | 428 mm | 434 mm |
| Top Tube Length | 575 mm | 590 mm | 605 mm | 620 mm | 635 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 366 mm | 417 mm | 467 mm | 505 mm | 543 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 114 mm | 124 mm | 134 mm | 144 mm | 154 mm |
| Chainstay Length | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Wheelbase | 1091 mm | 1095 mm | 1105 mm | 1110 mm | 1112 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 738 mm | 761 mm | 791 mm | 815 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
DS 3 belongs to the Trek Ds model. Trek launched 8 bikes of this model so far. You can get a glimpse at all models from 2018, by clicking on this link.
Model range prices
The most economical model, the Trek DS 1 2018 has a starting price of 489$. Trek DS 4 2018 on the other hand is the most expensive at 1069$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Hybrid bikes average price
According to our math, the average price for a trustworthy Hybrid bike is 562$. However, you could also get a good Hybrid bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Trek released this model in 2018, its price was 749$. Comparing the average cost of a Hybrid bike to this one, you will see that DS 3 price is 33.27% more expensive.
Hybrid bikes average weight
Hybrid bikes weigh an average of 13.85 kg (30.53 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
DS 3 weighs 13.73 kg (30.27 lbs) and is slightly lighter than the average. To sum up, it’s 0.87% lighter than the average weight of Hybrid bikes.
Overview of components
Fork
This bike has the SunTour NEX fork installed. The fork’s travel is 63mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
When leaving the production line, the DS 3 model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek DS 3 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
