Trek FX Sport 5 2019
2019 Urban
Estimate price |
1,889$
Weight | 10.06 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XL
185cm - 197cm
MD
164cm - 177cm
SM
154cm - 167cm
XS
147cm - 156cm
LG
174cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FX Sport 400 series OCLV carbon, IsoSpeed, 3s chain keeper, DuoTrap S compatible, flat mount disc, 12mm thru axle, hidden fender mounts
Suspension Fork
FX carbon, flat mount disc, hidden fender mounts, 12mm thru axle
Drivetrain
Rear Derailleur
Shimano Tiagra
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra rapid-fire, 10 speed
Cassette
Shimano Tiagra, 11-34, 10 speed
Crank
Shimano Tiagra, 50/34 (compact)
Bottom Bracket
Press Fit BB86.5
Chain
KMC X10
Pedals
VP nylon body w/alloy cage, toe-clip/strap
Wheels
Front Hub
Bontrager alloy sealed bearing, 12mm thru axle
Rear Hub
Bontrager alloy centerlock, 142x12
Rims
Bontrager Tubeless Ready Disc, 28h
Tires
Bontrager AW2 Hard-Case Lite, 700x32c, folding
Brakes
Brakes
Shimano MT-201, hydraulic disc
Cockpit
Stem
Bontrager Elite, 31.8mm, 7 degree, w/computer & light mounts
Handlebar
Bontrager Satellite Plus IsoZone, 31.8mm, 15mm rise
Grips
Bontrager Satellite IsoZone Plus, lock-on, ergonomic
Headset
1-1/8? threadless, sealed cartridge bearings
Seat
Saddle
Bontrager Montrose Comp
Seatpost
Bontrager alloy, 2-bolt head, 27.2mm, 8mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XL | MD | SM | XS | LG |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.41 mm | 1.44 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 615 mm | 626 mm | 637 mm | 642 mm | 650 |
| Rake | 50 mm | 50 mm | 49 mm | 45 mm | 44 mm |
| Trail | 74 mm | 71 mm | 70 mm | 67 mm | 63 mm |
| Stack | 540 mm | 565 mm | 591 mm | 618 mm | 647 mm |
| Reach | 395 mm | 402 mm | 410 mm | 416 mm | 426 mm |
| Top Tube Length | 538 mm | 557 mm | 577 mm | 597 mm | 627 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 72.5 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 135 mm | 160 mm | 185 mm | 210 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1052 mm | 1063 mm | 1074 mm | 1079 mm | 1087 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 691 mm | 719 mm | 750 mm | 788 mm | 825 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 185 cm | 164 cm | 154 cm | 147 cm | 174 cm |
| Rider Max Height | 197 cm | 177 cm | 167 cm | 156 cm | 187 cm |
About this model
FX Sport 5 belongs to the Trek Fx model. 128 bikes variations carry this model name so far. You can easily view all of the Trek Fx bikes models from 2019, here.
Model range prices
The most economical model, the Trek FX 1 Stagger 2019 has a starting price of 439$. Trek FX Sport 6 2019 on the other hand is the most expensive at 2099$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our math, the average price for a trustworthy Fitness bike is 656$. However, even though the average price of a Fitness bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1889$. Comparing this to the average Fitness bike price, we see that the price is 187.96% more expensive.
Average weight for Fitness bikes
On a deeper look, we notice that the average weight of a Fitness bike is 11.24 kg (24.78 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 10.06 kg (22.18 lbs), Trek bike is considerably lighter than average. In short, the average Fitness bike weight is 11.73% higher than this one.
FX Sport 5 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
As for the wheels, Trek FX Sport 5 2019, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek FX Sport 5 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This bike is available in 5 sizes. They vary from 185 cm – 187 cm (6.07 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
