Trek FX Sport 5 2020
2020 Urban
Estimate price |
1,889$
Weight | 10.35 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 156cm
SM
154cm - 166cm
MD
164cm - 176cm
LG
174cm - 187cm
XL
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
400 series OCLV carbon, IsoSpeed, internal routing, 3s chain keeper, DuoTrap S compatible, fender mounts, flat mount disc, 142x12mm thru axle
Suspension Fork
Size: S, M, L, XL, FX Carbon, threadless alloy steerer, hidden fender mounts, flat mount disc, 405mm axle-to-crown, 100x12mm thru axle; Size: S, M, L, XL, FX Carbon, flat mount disc, hidden fender mounts, 405mm axle-to-crown, 100x12mm thru axle
Drivetrain
Rear Derailleur
Shimano Tiagra 4700, long cage, 34T max cog
Front Derailleur
Shimano Tiagra 4700, braze-on
Shift Levers
Shimano Tiagra 4700, 10 speed
Cassette
Shimano Tiagra HG500, 11-34, 10 speed
Crank
Size: S, Shimano Tiagra 4700, 50/34, 170mm length; Size: M, L, Shimano Tiagra 4700, 50/34, 172.5mm length; Size: XL, Shimano Tiagra 4700, 50/34, 175mm length
Bottom Bracket
Shimano BB71, 86.5mm, PressFit
Chain
KMC X10
Wheels
Front Hub
Bontrager alloy, sealed bearing, centerlock disc, 100x12mm thru axle
Rear Hub
Bontrager alloy, sealed bearing, centerlock disc, Shimano 11-speed freehub, 142x12mm thru axle
Rims
Bontrager Affinity Disc, Tubeless Ready, 28-hole, presta valve
Spokes
14g, stainless steel, black
Tires
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x32c
Brakes
Brakes
Shimano MT201 hydraulic disc, flat mount, 160mm rotor
Disk Rotors
Shimano RT10, 160mm, centerlock
Cockpit
Stem
Size: S, M, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 100mm length; Size: L, XL, Bontrager Elite, 31.8mm clamp, Blendr compatible, 7 degree, 110mm length
Handlebar
Size: S, Bontrager Satellite Plus IsoZone, alloy, 31.8mm, 15mm rise, 600mm width; Size: M, L, XL, Bontrager Satellite Plus IsoZone, alloy, 31.8mm, 15mm rise, 660mm width
Grips
Bontrager Satellite IsoZone Plus, lock-on, ergonomic
Headset
1-1/8'' threadless, sealed cartridge bearings
Seat
Saddle
Bontrager Montrose Comp, steel rails, 138mm width
Seatpost
Bontrager Comp, 6061 alloy, 27.2mm, 8mm offset, 330mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.41 mm | 1.44 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 615 mm | 626 mm | 637 mm | 642 mm | 650 |
| Rake | 50 mm | 50 mm | 49 mm | 45 mm | 44 mm |
| Trail | 74 mm | 71 mm | 70 mm | 67 mm | 63 mm |
| Stack | 540 mm | 565 mm | 591 mm | 618 mm | 647 mm |
| Reach | 395 mm | 402 mm | 410 mm | 416 mm | 426 mm |
| Top Tube Length | 538 mm | 557 mm | 577 mm | 597 mm | 627 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 72.5 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.5 ° | 72.5 ° |
| Head Tube Length | 110 mm | 135 mm | 160 mm | 185 mm | 210 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1052 mm | 1063 mm | 1074 mm | 1079 mm | 1087 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 691 mm | 719 mm | 750 mm | 788 mm | 825 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 147 cm | 154 cm | 164 cm | 174 cm | 185 cm |
| Rider Max Height | 156 cm | 166 cm | 176 cm | 187 cm | 197 cm |
About this model
FX Sport 5 belongs to the Trek Fx model. 128 bikes variations carry this model name so far. Take a sneak peek at all Trek Fx bikes models from 2020, by clicking here.
Model range prices
Trek FX 1 Stagger 2020 is the cheapest bike model and costs 439$. Trek FX Sport 6 2020 is the most expensive one and costs 2099$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Fitness bikes average price
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, you could also get a good Fitness bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Trek released this model in 2020, its price was 1889$. Comparing this to the average Fitness bike price, we see that the price is 187.96% more expensive.
Fitness bikes average weight
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 10.35 kg (22.82 lbs), the FX Sport 5 model is a bit lighter than average. In other words, this model is 8.6% lighter than the average Fitness bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
FX Sport 5 has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The FX Sport 5 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek FX Sport 5 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 147 cm – 197 cm (4.82 ft – 6.46 ft). In conclusion, you won’t have a problem finding one that suits you.
