Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 27.5" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, SRAM -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 167cm
MD
170cm - 184cm
LG
181cm - 194cm
XL
192cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XC - Trail 29" / 27.5" AE81 ALLITE® Super Mag™, VAAST XC / Trail geometry, internal cable routing, dropper post ready
Suspension Fork
RockShox 35 Gold RL, 120mm Travel, DebonAir, 44mm offset, 15x110mm BOOST™
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM 11-50T, 12-Speed
Crank
Praxis Cadet M30, w/SRAM X-SYNC 32T Chainring
Bottom Bracket
Praxis T47 IB Enduro Bearings
Chain
SRAM 12sp
Wheels
Rims
Stans Notubes Flow D 27.5, 32H w/Stans tubeless rim tape
Spokes
Double butted stainless
Tires
Maxxis Ardent Race, 27.5" x 2.6", EXO/Tubeless Ready
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano 180mm F / 160mm R
Cockpit
Stem
VAAST MTB Pro
Handlebar
VAAST MTB Pro, 15mm rise w/7 degree sweep, 780mm width
Seat
Saddle
WTB Volt 142 Sport
Seatpost
TranzX 30.9mm dropper post, (100mm S/M, 120mm L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.48 mm | 1.43 mm | 1.4 mm |
| Bottom Bracket Height | 295 mm | 295 mm | 295 mm | 295 mm |
| Front Center | 664 mm | 690 mm | 715 mm | 741 mm |
| Rake | 39 mm | 39 mm | 40 mm | 40 mm |
| Trail | 102 mm | 102 mm | 100 mm | 100 mm |
| Stack | 613 mm | 618 mm | 627 mm | 641 mm |
| Reach | 393 mm | 418 mm | 438 mm | 458 mm |
| Top Tube Length | 575 mm | 600 mm | 624 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 415 mm | 450 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1090 mm | 1117 mm | 1142 mm | 1167 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 746 mm | 772 mm | 802 mm | 838 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 160 cm | 170 cm | 181 cm | 192 cm |
| Rider Max Height | 167 cm | 184 cm | 194 cm | 203 cm |
Model Overview
M/1 – TRAIL 27.5 completes the Vaast M1 model. Vaast launched 5 bikes of this model so far. You can easily view all of the Vaast M1 bikes models from 2020, here.
Model range prices
The most economical model, the Vaast M/1 – TRAIL 27.5 2020 has a starting price of 2099$. Vaast M/1 – XC 29 2020 on the other hand is the most expensive at 2099$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2020 and its price was 2099$. If we compare this with the average Trail bike cost we notice that the price is 31.59% lower.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
M/1 – TRAIL 27.5 components
Fork
The RockShox 35 Gold RL is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the M/1 – TRAIL 27.5 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The M/1 – TRAIL 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Vaast M/1 – TRAIL 27.5 bike has 4 sizes, in the range of 160 cm – 203 cm (5.25 ft – 6.66 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
