Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 29" -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 167cm
MD
170cm - 184cm
LG
181cm - 194cm
XL
192cm - 203cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
XC - Trail 29" / 27.5" AE81 ALLITE® Super Mag™, VAAST XC / Trail geometry, internal cable routing, dropper post ready
Suspension Fork
RockShox 35 Gold RL, 120mm Travel, DebonAir, 51mm offset, 15x110mm BOOST™
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX, 12-speed
Cassette
Shimano 10-51T, 12-speed
Crank
Praxis Cadet M30, 32T
Bottom Bracket
Praxis T47 IB Enduro Bearings
Chain
KMC X12 Nickel plated
Wheels
Rims
Stans NoTubes Arch S1, 28H w/Stans tubeless rim tape
Spokes
Double butted stainless
Tires
Maxxis Recon 29 x 2.4"F / 2.25"R, EXO/Tubeless Ready
Brakes
Brakes
Shimano MT200
Disk Rotors
Shimano 180mm F / 160mm R
Cockpit
Stem
VAAST MTB Pro
Handlebar
VAAST MTB Pro, 15mm rise w/7 degree sweep, 780mm width
Seat
Saddle
WTB Silverado 142 Race
Seatpost
TranzX 30.9mm dropper post, (100mm S/M, 120mm L/XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.48 mm | 1.43 mm | 1.4 mm |
| Bottom Bracket Height | 314 mm | 314 mm | 314 mm | 314 mm |
| Front Center | 664 mm | 690 mm | 715 mm | 741 mm |
| Rake | 39 mm | 39 mm | 40 mm | 40 mm |
| Trail | 109 mm | 109 mm | 108 mm | 108 mm |
| Stack | 613 mm | 618 mm | 627 mm | 641 mm |
| Reach | 393 mm | 418 mm | 438 mm | 458 mm |
| Top Tube Length | 575 mm | 600 mm | 624 mm | 648 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 415 mm | 450 mm | 480 mm | 530 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 135 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1090 mm | 1117 mm | 1142 mm | 1167 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 746 mm | 772 mm | 802 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 160 cm | 170 cm | 181 cm | 192 cm |
| Rider Max Height | 167 cm | 184 cm | 194 cm | 203 cm |
Model Overview
M/1 – XC 29 is part of the Vaast M1 model. Vaast released 5 bikes variations of this model so far. You can easily view all of the Vaast M1 bikes models from 2020, here.
Model range prices
The most economical model, the Vaast M/1 – TRAIL 27.5 2020 has a starting price of 2099$. Vaast M/1 – XC 29 2020 on the other hand is the most expensive at 2099$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2020 for 2099$. Comparing the average cost of a Trail bike to this one, you will see that M/1 – XC 29 price is 31.59% lower.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
Vaast M/1 – XC 29 2020 bike is equipped with the RockShox 35 Gold RL fork, and has 120mm travel. Bike forks are great for shock absorption and provide you with a smooth ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The M/1 – XC 29 2020 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
For your safety, it is important to have quality breaks on your bike. Vaast M/1 – XC 29 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 160 cm – 203 cm (5.25 ft – 6.66 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the M/1 – XC 29. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
