Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Magnesium -
Wheels 700c -
Groupset 105, Praxis -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
155cm - 163cm
SM
160cm - 170cm
MD
167cm - 177cm
LG
174cm - 184cm
XL
180cm - 189cm
XXL
187cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Road 700c disc, AE81 SuperMag, VAAST Road geometry, internal cable routing, fender ready. Up to 30mm tire clearance
Suspension Fork
VAAST Road full-carbon disc. Up to 30mm tire clearance
Drivetrain
Rear Derailleur
Shimano 105 R7000-SS
Front Derailleur
Shimano 105 R7000, braze-on
Shift Levers
Shimano 105 R7020 hydraulic disc
Cassette
Shimano 105 R7000, 11-speed, 11-30t
Crank
Praxis Alba M24, 50/34t
Bottom Bracket
Praxis T47 IB Enduro Bearings
Chain
KMC X11 11-speed
Wheels
Rims
VAAST Aluminum, Tubeless ready
Spokes
Black stainless
Tires
Vittoria Zaffiro Pro, 700 x 25mm w/Ultralight tubes
Brakes
Brakes
Shimano 105 R7070, hydraulic disc
Cockpit
Stem
VAAST Aero Pro, 3D forged, 8 degree
Handlebar
VAAST Aero, butted 6061 aluminum, 74mm reach/116mm drop
Seat
Saddle
Prologo Scratch RS
Seatpost
VAAST Carbon fiber, (300mm 49/52, 350mm 54/56/58/60)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.38 mm | 1.42 mm | 1.45 mm | 1.47 mm | 1.47 mm |
| Bottom Bracket Height | 269 mm | 269 mm | 272 mm | 272 mm | 275 mm | 275 mm |
| Front Center | 575 mm | 575 mm | 591 mm | 590 mm | 610 mm | 629 mm |
| Rake | 52 mm | 52 mm | 52 mm | 45 mm | 45 mm | 45 mm |
| Trail | 65 mm | 59 mm | 56 mm | 57 mm | 57 mm | 57 mm |
| Stack | 502 mm | 512 mm | 542 mm | 567 mm | 592 mm | 612 mm |
| Reach | 367 mm | 372 mm | 382 mm | 390 mm | 402 mm | 415 mm |
| Top Tube Length | 496 mm | 513 mm | 542 mm | 563 mm | 582 mm | 602 mm |
| Seat Tube Angle | 75.5 ° | 74.5 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 70.5 ° | 71.5 ° | 72 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 94 mm | 101 mm | 129 mm | 153 mm | 183 mm | 204 mm |
| Chainstay Length | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 975 mm | 975 mm | 990 mm | 992 mm | 1011 mm | 1031 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 724 mm | 744 mm | 768 mm | 790 mm | 814 mm | 834 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 160 cm | 167 cm | 174 cm | 180 cm | 187 cm |
| Rider Max Height | 163 cm | 170 cm | 177 cm | 184 cm | 189 cm | 196 cm |
About this model
R/1 700C 105 is a Vaast R1 model. 7 bikes variations carry this model name so far. You can easily view all of the Vaast R1 bikes models from 2022, here.
Model range prices
Vaast R/1 700C 105 2022 is the most economical model, with a starting price of 2299$. Vaast R/1 700C FORCE AXS 2022 on the other hand costs 4999$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Race bikes average price
If you want an acceptable Race bike you should know that the average price is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2299$. Doing a quick comparison, we notice that R/1 700C 105 price is 45.72% lower than the average cost of a Race bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Vaast R/1 700C 105 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vaast R/1 700C 105 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 155 cm – 196 cm (5.09 ft – 6.43 ft). In short, you can easily find one that suits you.
