Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ekar -
Suspension Rigid -
Drivetrain 1 × 13 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
162cm - 173cm
MD
169cm - 180cm
MD/LG
175cm - 186cm
LG
180cm - 192cm
XL
188cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ventum GS1 Disc, Material: Carbon, 12x142mm, Flat Mount Brake
Suspension Fork
Ventum GS1 Fork, Material: Carbon, 12x100mm, Flat Mount Brake, Flip Chip
Drivetrain
Rear Derailleur
Ekar Rear Derailleur
Front Derailleur
N/A
Shift Levers
Ekar Ergopower Shifter Controls
Cassette
Ekar 13 Speed
Wheels
Rims
Campagnolo Ekar
Brakes
Brakes
Hydraulic Disc
Cockpit
Handlebar
ENVE Gravel Bar or ENVE AR Bar
Seat
Seatpost
Ventum Seatpost, Material: Carbon, 400mm Length, 25mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.46 mm | 1.5 mm | 1.51 mm | 1.51 mm |
| Bottom Bracket Height | 279 mm | 279 mm | 279 mm | 279 mm | 279 mm |
| Front Center | 592 mm | 604 mm | 612 mm | 617 mm | 626 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 79 mm | 76 mm | 69 mm | 63 mm | 60 mm |
| Stack | 516 mm | 539 mm | 564 mm | 583 mm | 598 mm |
| Reach | 359 mm | 368 mm | 377 mm | 386 mm | 395 mm |
| Top Tube Length | 524 mm | 540 mm | 557 mm | 572 mm | 585 mm |
| Seat Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Seat Tube Length | 547 mm | 571 mm | 598 mm | 618 mm | 633 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 71 ° | 72 ° | 72.5 ° |
| Head Tube Length | 105 mm | 128 mm | 150 mm | 166 mm | 180 mm |
| Chainstay Length | 414 mm | 414 mm | 414 mm | 414 mm | 414 mm |
| Wheelbase | 996 mm | 1008 mm | 1016 mm | 1021 mm | 1030 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 162 cm | 169 cm | 175 cm | 180 cm | 188 cm |
| Rider Max Height | 173 cm | 180 cm | 186 cm | 192 cm | 199 cm |
Model Overview
GS1 CAMPAGNOLO EKAR completes the Ventum Gs1 model. Ventum launched 15 bikes of this model so far. Take a sneak peek at all Ventum Gs1 bikes models from 2022, by clicking here.
Model range prices
Ventum GS1 SRAM RIVAL XPLR AXS 2022 is the most affordable bike of this model and has a price of 4199$. On the other hand, Ventum GS1 SRAM RED AXS MULLET 2022, is the most expensive and costs 7499$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
According to our calculations, the average cost of a Gravel bike that is reliable is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Ventum GS1 CAMPAGNOLO EKAR price was 5999$. Doing a quick comparison, we notice that GS1 CAMPAGNOLO EKAR price is 143.66% more expensive than the average cost of a Gravel bike.
GS1 CAMPAGNOLO EKAR components
Fork material
GS1 CAMPAGNOLO EKAR has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Ventum GS1 CAMPAGNOLO EKAR 2022, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Ventum GS1 CAMPAGNOLO EKAR has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
GS1 CAMPAGNOLO EKAR comes in 5 sizes, that range from 162 cm – 199 cm (5.31 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
