Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 120mm -
Fork SunTour XCR 32 Air
-
Groupset Acera, Suntour -
Suspension Hardtail -
Drivetrain 2 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 152cm
MD
167cm - 152cm
LG
177cm - 182cm
XL
188cm - 182cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061-T6, long, slack & low modern geometry
Suspension Fork
120mm Suntour SF19-XCR32 Air, Boost
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Acera, 9 speed
Front Derailleur
Shimano Acera, 2 speed
Shift Levers
Shimano Acera, 2x9 speed
Cassette
Shimano CS-HG201-9 11-36t, 9 speed
Crank
Suntour CW15-XCM, 175mm, 36x22T
Bottom Bracket
Suntour, Threaded 73mm BSA
Chain
KMC Z9, 9 speed
Wheels
Front Hub
KT, 32H, 110x15mm
Rear Hub
KT, 32H, 135x10mm
Rims
WTB ST i29
Spokes
N/A
Tires
WTB Vigilante Comp (F) TrailBoss Comp (R), 27.5x2.3” with High Grip Compound (F) 27.5x2.25”(R)
Brakes
Brakes
Tektro HD-M290, 160mm rotor
Cockpit
Stem
Vitus, 50mm
Handlebar
Nukeproof Neutron, 31.8mm 25mm rise Widths - S 740mm M 760mm L 780mm XL 780mm
Headset
FSA, 1 1/8 - 1.5 tapered
Seat
Saddle
Vitus
Seatpost
Vitus, 31.6
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.37 mm | 1.33 mm | 1.29 mm |
| Bottom Bracket Height | 310 mm | 310 mm | 310 mm | 310 mm |
| Front Center | 707 mm | 725 mm | 746 mm | 775 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 107 mm | 109 mm | 109 mm | 106 mm |
| Stack | 589 mm | 594 mm | 603 mm | 612 mm |
| Reach | 417 mm | 435 mm | 452 mm | 474 mm |
| Top Tube Length | 597 mm | 617 mm | 637 mm | 662 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 380 mm | 432 mm | 483 mm | 520 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 422 mm | 422 mm | 422 mm | 422 mm |
| Wheelbase | 1125 mm | 1143 mm | 1164 mm | 1193 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 157 cm | 167 cm | 177 cm | 188 cm |
| Rider Max Height | 152 cm | 152 cm | 182 cm | 182 cm |
Model Overview
Nucleus 27 VRS belongs to the Vitus Nucleus model. Vitus launched 65 bikes of this model so far. You can easily view all of the Vitus Nucleus bikes models from 2019, here.
Model range prices
The most economical model, the Vitus Nucleus 24 Kids 2019 has a starting price of 485$. Vitus Nucleus 27 VRX 2019 on the other hand is the most expensive at 850$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 729$. Comparing this to the average Trail bike price, we see that the price is 278.88% smaller.
Overview of components
Fork
This bike has the SunTour XCR 32 Air fork installed. The fork’s travel is 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
The Nucleus 27 VRS 2019 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Vitus Nucleus 27 VRS is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
This bike is available in 4 sizes. They vary from 157 cm – 182 cm (5.15 ft – 5.97 ft). In short, you can easily find one that suits you.
