Vitus ZX1 Aero Disc 105 2018
2018 Road
Estimate price |
2,675$
Weight | 8.68 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset 105 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
161cm - 169cm
SM
166cm - 175cm
MD
172cm - 181cm
LG
178cm - 157cm
XL
154cm - 187cm
XXL
184cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, UD Carbon, 142x12mm Thru axle
Suspension Fork
Carbon, UD Carbon, Tapered steerer
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano 105, 11 speed gs cage
Front Derailleur
Shimano 105, 2x Braze on
Shift Levers
Shimano 105, 2 x 11 speed
Cassette
shimano 105, 11 speed 11-28t
Crank
Shimano 105, 52x36t, 49/52cm-170mm, 54/56cm-172.5mm, 58/60/62cm-175mm
Bottom Bracket
Shimano, BB-71 Press fit
Chain
KMC X11L
Wheels
Front Hub
Mavic, 100x12mm Thru axle
Rear Hub
Mavic, 142x12mm Thru axle
Rims
Mavic Cosmic Ellite Disc, Black
Spokes
Double butted
Tires
Continental Ultra sport II, 700x25c
Brakes
Brakes
Shimano BR-RS505, 160mm
Cockpit
Stem
Prime alloy, Alloy, 49/52cm-100mm, 54/56cm-110mm, 58/60/62cm-120mm
Handlebar
Prime alloy, Alloy, 49/52cm-400mm, 54/56cm-420mm, 58/60cm-440mm
Headset
Ritchey, Comp Logic Zero Drop In 1 1/8
Seat
Saddle
Prime
Seatpost
Prime carbon, Aero
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.43 mm | 1.42 mm | 1.41 mm | 1.43 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 267 mm | 269 mm | 269 mm |
| Front Center | 569 mm | 573 mm | 580 mm | 591 mm | 608 mm | 619 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 67 mm | 60 mm | 58 mm | 58 mm | 58 mm | 58 mm |
| Stack | 508 mm | 525.5 mm | 539.5 mm | 548.5 mm | 561 mm | 579.5 mm |
| Reach | 362 mm | 369.5 mm | 377 mm | 385 mm | 398 mm | 404 mm |
| Top Tube Length | 507 mm | 523 mm | 539 mm | 555 mm | 572 mm | 589 mm |
| Seat Tube Angle | 74.3 ° | 74 ° | 73.5 ° | 73 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 460 mm | 480 mm | 500 mm | 525 mm | 550 mm | 570 mm |
| Head Tube Angle | 71.5 ° | 72.5 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 130 mm | 145 mm | 155 mm | 170 mm | 190 mm |
| Chainstay Length | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm | 402 mm |
| Wheelbase | 959 mm | 964 mm | 971 mm | 983 mm | 1001 mm | 1012 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 69 mm | 67 mm | 67 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 161 cm | 166 cm | 172 cm | 178 cm | 154 cm | 184 cm |
| Rider Max Height | 169 cm | 175 cm | 181 cm | 157 cm | 187 cm | 195 cm |
Model Overview
ZX1 Aero Disc 105 belongs to the Vitus Zx1 model. Vitus released 6 bikes variations of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Vitus ZX1 Aero Disc 105 2018 is the most economical model, with a starting price of 2432$. Vitus ZX1 Team Aero Disc Dura-Ace 2018 on the other hand costs 5108$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Aero bikes average price
According to our calculations, the average cost of an Aero bike that is reliable is 4211$. However, this doesn’t mean that if you spend less money on an Aero bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Vitus ZX1 Aero Disc 105 price was 2432$. Comparing this to the average Aero bike price, we see that the price is 73.15% smaller.
Aero bikes average weight
Aero bikes have an average weight of 7.34 kg (16.18 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 8.68 kg (19.14 lbs), the ZX1 Aero Disc 105 model is much heavier than average. In other words, this model is 18.26% heavier than the average Aero bike.
Overview of components
Fork material
When it comes to the fork, this bike has a carbon one, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels
As for the wheels, Vitus ZX1 Aero Disc 105 2018, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Vitus ZX1 Aero Disc 105 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 161 cm – 195 cm (5.28 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
