Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox 35 Gold RL
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy, SCR Aluminium Front Triangle with Tapered Head Tube and Intergrip Seat Clamp System, ISCG, 2 Bolt Guide Mounts, Alloy Symmetrical SCR Rear Triangle, 148mm Boost Dropouts
Suspension Fork
RockShox 35 Gold RL 27.5", 140mm Travel, 37mm Offset, DebonAir, Motion Control Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear Shock
RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position Compression
Drivetrain
Rear Derailleur
Shimano Deore RD-M5100-SGS, Shadow Plus, 11 Speed
Front Derailleur
N/A
Shift Levers
Shimano Deore M5100, I-Spec EV 11 Speed, Black
Cassette
SunRace CSMS8, 11-51, 11 Speed
Crank
Whyte, Forged 2pcs Cranks, Direct Mount 32T Narrow Wide Boost Chainring, 170mm, Boost, 11 Speed
Bottom Bracket
BSA, Cartridge Bearings, 73mm
Chain
SunRace, 11 Speed
Pedals
None
Wheels
Front Hub
Shimano MT410-B, Cartridge Bearings, centre lock, 15mm x 110mm Boost Through Axle, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, Centre Lock 12mm x 148mm Boost Through Axle, 32 Hole
Rims
WTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis High Roller II TR 27.5" x 2.6" 120TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Rekon TR 27.5" x 2.6" 60TPI, EXO Sidewall Protection, 3C Maxx Terra, Rear
Brakes
Brakes
Shimano Deore MT-M6120, 4 Piston, 180mm Disc
Brake Levers
Shimano Deore BR-M6100, I-Spec EV
Cockpit
Stem
Whyte Gravity Stem, 35mm Extension
Handlebar
Whyte 6061 Alloy, 31.8mm, XS/S 15mm Rise, 760mm Wide, M/L/XL, 30mm Rise 780mm Wide
Grips
Whyte Lock-on V Grip
Headset
FSA No. 57 Orbit ZS, ACB, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Dual Density, Triple Panel Design
Seatpost
Trans-X, 30.9mm, XS 100mm Travel, S 125mm Travel, M/L/XL 150mm Travel, Shimano Remote Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.37 mm | 1.35 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm | 327 mm | 327 mm |
| Stack | 595.3 mm | 596.3 mm | 618.3 mm | 632.3 mm | 641.3 mm |
| Reach | 410.3 mm | 434.3 mm | 458.3 mm | 482.3 mm | 506.3 mm |
| Top Tube Length | 557.3 mm | 585.3 mm | 614.3 mm | 642.3 mm | 671.3 mm |
| Seat Tube Angle | 74.9 ° | 74.7 ° | 74.5 ° | 74.3 ° | 74.1 ° |
| Seat Tube Length | 368.3 mm | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° | 65.6 ° |
| Head Tube Length | 100 mm | 112 mm | 125 mm | 140 mm | 150 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1141 mm | 1170 mm | 1200 mm | 1230 mm | 1258 mm |
| Bottom Bracket Drop | 28 mm | 28 mm | 28 mm | 28 mm | 28 mm |
| Standover Height | 790 mm | 798 mm | 804 mm | 810 mm | 817 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
T-140 SR V1 completes the Whyte T 140 model. There are 6 bikes that carry this model name. You can easily view all of the Whyte T 140 bikes models from 2021, here.
Model range prices
The most economical model, the Whyte T-140 SR V1 2021 has a starting price of 2980$. Whyte T-140 S V1 2021 on the other hand is the most expensive at 3406$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2980$. In conclusion, this bike price is 7.89% higher than the price of the average Trail bike.
Overview of components
Fork
The RockShox 35 Gold RL is included from the factory. It has a travel distance of 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the T-140 SR V1 model has 27.5″ aluminum wheels. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Whyte T-140 SR V1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Whyte T-140 SR V1 bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
A dropper post is included with the T-140 SR V1. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
