Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Fork RockShox Pike Select
-
Groupset GX Eagle, X1 -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon, Uni-directional Multi Monocoque Front Triangle with Internal Cable Routing, Tapered Head Tube, ISCG, 2 Bolt Guide Mounts, Alloy Symmetrical SCR Rear Triangle, Shape.it and 148mm Boost Dropouts
Suspension Fork
RockShox Pike Select RC 27.5"", 140mm Travel, 37mm Offset, DebonAir, Charger RC Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate
Rear Shock
RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position Compression
Drivetrain
Rear Derailleur
SRAM GX Eagle Lunar, 12 Speed
Front Derailleur
N/A
Shift Levers
SRAM GX Eagle Lunar, MMX Clamp, 12 Speed
Cassette
SRAM PG-1230 Eagle, 11-50, 12 Speed
Crank
SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost, 12 Speed
Bottom Bracket
SRAM DUB, BSA, 73mm
Chain
SRAM GX Eagle, 12 Speed
Pedals
None
Wheels
Front Hub
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole
Rear Hub
Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
Rims
WTB ST i30 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
Spokes
DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples
Tires
Maxxis Minion DHF TR 27.5"" x 2.6"" 120TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Dissector TR 27.5"" x 2.6"" 120TPI, EXO+ Sidewall Protection, 3C Maxx Terra, Rear
Brakes
Brakes
SRAM Guide G2 R, 4 Piston, 180mm Disc
Brake Levers
SRAM Guide G2 R, Matchmaker
Cockpit
Stem
Whyte Gravity Stem, 35mm Extension
Handlebar
Whyte 6061 Alloy, 31.8mm, S 15mm Rise, 760mm Wide, M/L/XL, 30mm Rise 780mm Wide
Grips
Whyte Lock-on Enduro Grip
Headset
FSA No. 42 Orbit ZS Plus, Integrated, 1 1/2"" Lower and 1 1/8"" Upper Sealed Cartridge Bearings
Seat
Saddle
Whyte Custom, Dual Density, Triple Panel Design
Seatpost
Whyte drop.it II Adjust, 30.9mm, S/M 120-150mm Travel, L/XL 140-170mm Travel, Paddle Remote Lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Bottom Bracket Height | 330.1 mm | 330.1 mm | 330.1 mm | 330.1 mm |
| Stack | 600.4 mm | 622.4 mm | 636.4 mm | 645.4 mm |
| Top Tube Length | 589.4 mm | 618.4 mm | 646.4 mm | 675.4 mm |
| Seat Tube Angle | 74.7 ° | 74.5 ° | 74.3 ° | 74.1 ° |
| Seat Tube Length | 406.4 mm | 431.8 mm | 457.2 mm | 482.6 mm |
| Head Tube Angle | 65.9 ° | 65.9 ° | 65.9 ° | 65.9 ° |
| Head Tube Length | 112 mm | 125 mm | 140 mm | 150 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1174 mm | 1204 mm | 1234 mm | 1262 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm | 25 mm |
| Standover Height | 802 mm | 808 mm | 814 mm | 821 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
T-140C R belongs to the Whyte T 140c model. There are 6 bikes that carry this model name. You can easily view all of the Whyte T 140c bikes models from 2023, here.
Model range prices
Whyte T-140C R 2023 is the cheapest bike model and costs 5108$. Whyte T-140C RSX 2023 is the most expensive one and costs 6689$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Whyte released this model in 2023, its price was 5108$. If we compare this with the average Trail bike cost we notice that the price is 84.94% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
T-140C R components
Fork
Whyte T-140C R 2023 bike is equipped with the RockShox Pike Select fork, and has 140mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The wheels on T-140C R are the 27.5″ aluminum type. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Whyte T-140C R has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
T-140C R comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Whyte T-140C R comes with a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
