Wilier 503X RACE – SHIMANO XT 1×12 2.0 2023
2023 Road
Estimate price |
1,861$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 29" -
Fork RockShox Reba -
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALU 6066/6061 DOUBLE BUTTED
Suspension Fork
ROCK SHOX REBA RL, 100 mm
Drivetrain
Rear Derailleur
SHIMANO XT 1X12 RD-M8100-SGS
Front Derailleur
-
Shift Levers
SHIMANO DEORE M6100-R
Cassette
SHIMANO SLX 12S CS-M7100-12 10-51T
Crank
SHIMANO FC-MT510 32T
Bottom Bracket
SHIMANO PRESSFIT MT500-PA
Chain
SHIMANO SLX CN-M7100 118 LINK
Wheels
Rims
SHIMANO MT501
Tires
VITTORIA BARZO 29" X 2.25 RIGID
Brakes
Brakes
SHIMANO MT401
Disk Rotors
SHIMANO RT30 180 mm / 160 mm
Cockpit
Stem
PROMAX DA282
Handlebar
PROMAX HB-3018
Headset
RITCHEY COMP PRD15862
Seat
Saddle
SELLE ITALIA MODEL X
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.52 mm | 1.49 mm | 1.46 mm |
| Stack | 620 mm | 631 mm | 642 mm | 653 mm |
| Reach | 398 mm | 415 mm | 431 mm | 447 mm |
| Top Tube Length | 583 mm | 603 mm | 628 mm | 653 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 420 mm | 450 mm | 490 mm | 530 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 112 mm | 124 mm | 135 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 164 cm | 169 cm | 174 cm | 179 cm |
| Rider Max Height | 172 cm | 177 cm | 182 cm | 186 cm |
Model Overview
503X RACE – SHIMANO XT 1×12 2.0 completes the Wilier 503x model. Wilier released 17 bikes variations of this model so far. You can easily view all of the Wilier 503x bikes models from 2023, here.
Model range prices
Wilier 503X PRO – SHIMANO DEORE 1×12 2023 is the most economical model, with a starting price of 1327$. Wilier 503X RACE – SHIMANO XT 1×12 2.0 2023 on the other hand costs 1699$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Race bikes
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Wilier 503X RACE – SHIMANO XT 1×12 2.0 price was 1699$. If we compare this with the average Race bike cost we notice that the price is 97.17% lower.
503X RACE – SHIMANO XT 1×12 2.0 components
Fork
The 503X RACE – SHIMANO XT 1×12 2.0 comes factory-installed with the RockShox Reba fork. This has a travel range of mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
As for the wheels, Wilier 503X RACE – SHIMANO XT 1×12 2.0 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 164 cm – 186 cm (5.38 ft – 6.1 ft). In conclusion, finding one for you shouldn’t be a problem.
