Wilier FILANTE HYBRID SHIMANO DURA ACE 9270 DI2 12S + MAHLE EBIKEMOTION 2023
2023 E-bike
Estimate price |
14,309$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Motor MAHLE mid-drive -
Battery 250 WH, 36 V, ANT+ CONNECTIVITY -
Drivetrain Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 165cm
SM
162cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Suspension Fork
FILANTE HY - CARBON MONOCOQUE HUS-MOD
Drivetrain
Rear Derailleur
SHIMANO DURA ACE RD-R9250 Di2
Front Derailleur
SHIMANO DURA ACE FD-R9250 Di2
Shift Levers
SHIMANO DURA ACE ST-R9270 DI2
Cassette
SHIMANO DURA ACE CS-R9200 12S
Crank
SHIMANO DURA ACE FC-R9200
Bottom Bracket
SHIMANO DURA ACE PRESS FIT SM-BB92
Chain
SHIMANO DURA ACE CN-M9100 12S
Wheels
Rims
WILIER TRIESTINA HY-SLR42KC CARBON DISC WILIER TRIESTINA HY-SLR42KC CARBON DISC
Tires
VITTORIA CORSA SPEED 700X28
Brakes
Brakes
SHIMANO DURA ACE BR-R9270
Disk Rotors
SHIMANO DURA ACE RT-MT900 CENTER LOCK 160 mm / 140 mm
Cockpit
Handlebar
FILANTE HY BAR INTEGRATED CARBON
Headset
FSA CUSTOM BEARINGS
Seat
Saddle
PROLOGO DIMENSION 143
Motor & Battery
Motor
MAHLE X20
Battery
250 WH, 36 V, ANT+ CONNECTIVITY
Remote
COMPUTER PULSAR ONE COMPUTER PULSAR ONE
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.42 mm | 1.45 mm | 1.49 mm | 1.52 mm | 1.55 mm | 1.58 mm |
| Stack | 532 mm | 551 mm | 571 mm | 591 mm | 609 mm | 630 mm |
| Reach | 374 mm | 379 mm | 384 mm | 389 mm | 394 mm | 400 mm |
| Top Tube Length | 522 mm | 537 mm | 552 mm | 563 mm | 579 mm | 597 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 405 mm | 435 mm | 455 mm | 475 mm | 505 mm | 535 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 196 mm | 217 mm |
| Chainstay Length | 411 mm | 411 mm | 413 mm | 413 mm | 416 mm | 416 mm |
| Wheelbase | 979 mm | 987 mm | 996 mm | 1003 mm | 1017 mm | 1029 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 162 cm | 169 cm | 174 cm | 179 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 177 cm | 182 cm | 187 cm | cm |
About this model
FILANTE HYBRID SHIMANO DURA ACE 9270 DI2 12S + MAHLE EBIKEMOTION completes the Wilier E Filante model. Wilier released 6 e-bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Wilier FILANTE HYBRID SHIMANO ULTEGRA DI2 R8170 12S + MAHLE EBIKEMOTION 2023 is the most affordable e-bike of this model and has a price of 9875$. On the other hand, Wilier FILANTE HYBRID SRAM RED AXS 2X12 + MAHLE EBIKEMOTION 2023, is the most expensive and costs 13272$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race e-bikes average price
If you want to purchase a solid Race e-bike, it is important to know that the average cost is 4156$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Race e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 13060$. In conclusion, this e-bike price is 214.24% more expensive than the price of the average Race e-bike.
FILANTE HYBRID SHIMANO DURA ACE 9270 DI2 12S + MAHLE EBIKEMOTION components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
The wheels on FILANTE HYBRID SHIMANO DURA ACE 9270 DI2 12S + MAHLE EBIKEMOTION are the 700c carbon type. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
