Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Motor MAHLE hub-drive -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
164cm - 172cm
MD
169cm - 177cm
LG
174cm - 182cm
XL
179cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CARBON MONOCOQUE NH-MOD
Suspension Fork
CARBON MONOCOQUE NH-MOD
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX812
Front Derailleur
SHIMANO GRX FD-RX815
Shift Levers
SHIMANO SL-RS700 FLAT 11S
Cassette
SHIMANO CS-M7000-11 11-42T
Crank
SHIMANO GRX FC-RX600-1 40T
Bottom Bracket
SHIMANO PRESSFIT
Chain
SHIMANO GRX CN-HG601-11
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC-EU
Tires
VITTORIA TERRENO DRY RIGID 700x40
Brakes
Brakes
SHIMANO BR-RS600 DISC
Disk Rotors
SHIMANO SM-RT66 160 mm 6 BOLT
Cockpit
Stem
RITCHEY COMP
Handlebar
RITCHEY FLAT BAR MTN COMP 2X BBBLK
Headset
FSA MR137 TAPERED 1"1/8 TOP - 1"1/4 BOTTOM
Seat
Saddle
SELLE ITALIA MODEL X
Motor & Battery
Motor
MAHLE EBIKEMOTION X35
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.52 mm | 1.55 mm | 1.58 mm |
| Stack | 558 mm | 584 mm | 610 mm | 635 mm |
| Reach | 375 mm | 384 mm | 394 mm | 403 mm |
| Top Tube Length | 531 mm | 555 mm | 578 mm | 602 mm |
| Seat Tube Angle | 72.8 ° | 73.7 ° | 73.1 ° | 72.8 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 570 mm |
| Head Tube Angle | 70.5 ° | 71 ° | 71.5 ° | 72 ° |
| Head Tube Length | 125 mm | 150 mm | 175 mm | 200 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Min Height | 164 cm | 169 cm | 174 cm | 179 cm |
| Rider Max Height | 172 cm | 177 cm | 182 cm | 186 cm |
Model Overview
Jena Hybrid is a Wilier E Jena model. There are 15 e-bikes that carry this model name. Take a sneak peek at all Wilier E Jena e-bikes models from 2023, by clicking here.
Model range prices
Wilier Jena Hybrid SHIMANO GRX 1×11 FLAT BAR 2023 is the most affordable e-bike of this model and has a price of 5203$. On the other hand, Wilier Jena Hybrid SHIMANO GRX Di2 2X11 2023, is the most expensive and costs 8388$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Gravel e-bikes average price
Our math shows that the average cost of a dependable Gravel e-bike is 3642$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Average weight for Gravel e-bikes
On a deeper look, we notice that the average weight of a Gravel e-bike is 13.58 kg (29.94 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Jena Hybrid weighs 13 kg (28.66 lbs) and is slightly lighter than the average. In conclusion, the average Gravel e-bike weighs 4.46% more than Jena Hybrid.
Overview of components
Fork material
Jena Hybrid has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Wilier Jena Hybrid 2023, has a 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Wilier Jena Hybrid has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
This e-bike is available in 4 sizes. They vary from 164 cm – 186 cm (5.38 ft – 6.1 ft). In conclusion, you won’t have a problem finding one that suits you.
