Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, 105 -
Suspension Rigid -
Motor MAHLE hub-drive -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 165cm
SM
155cm - 170cm
MD
167cm - 178cm
LG
175cm - 188cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRIESTINA HYBRID - ALU 6061, DOUBLE BUTTED
Suspension Fork
TRIESTINA HYBRID CARBON MONOCOQUE
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX812
Front Derailleur
SHIMANO 105 FD-R7000
Shift Levers
SHIMANO SLRS700
Cassette
SHIMANO CS-M7000-11 11-42T
Crank
SHIMANO GRX FC-RX600-1 40T
Bottom Bracket
SHIMANO PRESSFIT BB-RS500-PB
Chain
SHIMANO GRX CN-HG601-11 114 LINK
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC
Tires
VITTORIA TERRENO MIX RIGID 700x33
Brakes
Brakes
SHIMANO BR-RS405 + BLRS600
Disk Rotors
SHIMANO SM-RT66 6 BOLTS 160 mm / 160 mm
Cockpit
Stem
PROMAX DA282
Handlebar
PROMAX HB-3018DB 12° FLARE OUT
Headset
RITCHEY PRD15862
Seat
Saddle
SELLE ITALIA MODEL X
Motor & Battery
Motor
MAHLE EBIKEMOTION X35+
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.55 mm |
| Stack | 526 mm | 545 mm | 565 mm | 585 mm | 603 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 388 mm |
| Top Tube Length | 514 mm | 530 mm | 546 mm | 557 mm | 573 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 196 mm |
| Chainstay Length | 405 mm | 405 mm | 407 mm | 407 mm | 410 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 155 cm | 167 cm | 175 cm | 185 cm |
| Rider Max Height | 165 cm | 170 cm | 178 cm | 188 cm | 195 cm |
About this model
TRIESTINA HYBRID completes the Wilier E Triestina model. 13 e-bikes variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 FLAT BAR 2023 is the cheapest e-bike model and costs 3663$. Wilier TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR 2023 is the most expensive one and costs 4141$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Hybrid e-bikes average price
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Average weight for Hybrid e-bikes
Hybrid e-bikes weigh an average of 23.79 kg (52.45 lbs). Having an easier bike than average will give you a great advantage on climbs. However, a heavier bike will gain more speed on descends.
Wilier TRIESTINA HYBRID it’s weighing 13.1 kg (28.88 lbs). At this weight, is much lighter than average. In conclusion, the average Hybrid e-bike weighs 81.6% more than TRIESTINA HYBRID.
Overview of components
Fork material
The fork on this e-bike is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When it comes to wheels, the TRIESTINA HYBRID e-bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The TRIESTINA HYBRID has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
