Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR 2023
2023 E-bike
Estimate price |
4,421$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Motor MAHLE hub-drive -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 165cm
SM
155cm - 170cm
MD
167cm - 178cm
LG
175cm - 188cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
TRIESTINA HYBRID - ALU 6061, DOUBLE BUTTED
Suspension Fork
TRIESTINA HYBRID CARBON MONOCOQUE
Drivetrain
Rear Derailleur
SHIMANO GRX RD-RX812
Shift Levers
SHIMANO GRX ST-RX600
Cassette
SHIMANO CS-M7000-11 11-42T
Crank
SHIMANO GRX FC-RX600-1 40T
Bottom Bracket
SHIMANO PRESSFIT BB-RS500-PB
Chain
SHIMANO GRX CN-HG601-11 114 LINK
Wheels
Rims
WILIER TRIESTINA HY-NDR28AC
Tires
VITTORIA TERRENO MIX RIGID 700x33
Brakes
Brakes
SHIMANO GRX BR-RX400
Disk Rotors
SHIMANO SM-RT66 6 BOLTS 160 mm / 160 mm
Cockpit
Stem
FSA OS-168 - CUSTOM WILIER
Handlebar
FSA OMEGA
Headset
RITCHEY PRD15862
Seat
Saddle
SELLE ITALIA MODEL X
Motor & Battery
Motor
MAHLE EBIKEMOTION X35+
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.46 mm | 1.49 mm | 1.53 mm | 1.55 mm |
| Stack | 526 mm | 545 mm | 565 mm | 585 mm | 603 mm |
| Reach | 368 mm | 373 mm | 378 mm | 383 mm | 388 mm |
| Top Tube Length | 514 mm | 530 mm | 546 mm | 557 mm | 573 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm |
| Head Tube Angle | 71 ° | 71.5 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 196 mm |
| Chainstay Length | 405 mm | 405 mm | 407 mm | 407 mm | 410 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 155 cm | 167 cm | 175 cm | 185 cm |
| Rider Max Height | 165 cm | 170 cm | 178 cm | 188 cm | 195 cm |
Model Overview
TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR belongs to the Wilier E Triestina model. 13 e-bikes variations carry this model name so far. Take a sneak peek at all Wilier E Triestina e-bikes models from 2023, by clicking here.
Model range prices
Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 FLAT BAR 2023 is the most economical model, with a starting price of 3663$. Wilier TRIESTINA HYBRID SHIMANO 105 R7020 DROP BAR 2023 on the other hand costs 4141$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Hybrid e-bikes average price
According to our calculations, the average cost of a Hybrid e-bike that is reliable is 2480$. However, even though the average price of a Hybrid e-bike is lower, you might still be able to get a top-quality e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR price was 4035$. Comparing this to the average Hybrid e-bike price, we see that the price is 62.7% more expensive.
TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR components
Fork material
The fork is made out of carbon, so, it’s a great addition to the e-bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Wilier TRIESTINA HYBRID SHIMANO GRX 1X11 DROP BAR has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
