Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus, Gates -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch, PowerTube, 625 Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour, NEX E25-HLO, Lockout, Steel spring, travel= 63 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Drivetrain
Shift Levers
Shimano, Nexus, Twist shifter
Cassette
Gates, sprocket
Crank
Gates, Aluminium, 46 teeth
Bottom Bracket
integrated in the motor
Chain
Gates, CarbonDrive
Chain Guide
Nylon directmount
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Zac421, Double Wall, Aluminium
Spokes
Sapim, Leader, Black
Tires
Schwalbe, Marathon Almotion, 55-584, 27.5" x 2.15"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT402, Aluminium,
Cockpit
Stem
XLC, A-Head verstellbar, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal, Viento
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line Smart System, 250W, 75 Nm
Battery
Bosch, PowerTube, 625 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 56cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.637 mm | 1.513 mm | 1.497 mm | 1.508 mm |
| Front Center | 666 mm | 675 mm | 685 mm | 696 mm |
| Rake | 33 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 69 mm | 69 mm | 69 mm |
| Stack | 673 mm | 637 mm | 642 mm | 656 mm |
| Reach | 411 mm | 421 mm | 429 mm | 435 mm |
| Top Tube Length | 632 mm | 641 mm | 649 mm | 658 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 155 mm | 160 mm | 175 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1134 mm | 1144 mm | 1154 mm | 1165 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 800 mm | 820 mm | 850 mm | 870 mm |
| Wheels | 650 | 650 | 650 | 650 |
Model Overview
Sinus R5 is part of the Winora E Sinus model. 18 e-bikes variations carry this model name so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Winora Sinus Tria 9 2024 is the most economical model, with a starting price of 3070$. Winora Sinus R380 auto 2024 on the other hand costs 5082$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter e-bikes average price
If you want an acceptable Commuter e-bike you should know that the average price is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4658$. If we compare this with the average Commuter e-bike cost we notice that the price is 81.32% more expensive.
Overview of components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The wheels on Sinus R5 are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Sinus R5 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
