Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Nexus, Gates -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch, PowerTube, 625 Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour, NEX E25-HLO, Lockout, Steel spring, travel= 63 mm, Aluminium steerer tube 1 1/8" - 1 1/2" tapered
Drivetrain
Shift Levers
Shimano, Nexus, Twist shifter
Cassette
Gates, sprocket
Crank
Gates, Aluminium, 46 teeth
Bottom Bracket
integrated in the motor
Chain
Gates, CarbonDrive
Chain Guide
Nylon directmount
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Zac421, Double Wall, Aluminium
Spokes
Sapim, Leader, Black
Tires
Schwalbe, Marathon Almotion, 55-584, 27.5" x 2.15"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT402, Aluminium,
Cockpit
Stem
XLC, A-Head verstellbar, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Grips
Herrmans, Click Ergo - lock on grips
Headset
Feimin, A-Head Tapered, Aluminium, Cartridge
Seat
Saddle
Selle Royal, Viento
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line Smart System, 250W, 75 Nm
Battery
Bosch, PowerTube, 625 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 52cm | 56cm | 60cm |
|---|---|---|---|---|
| Stack Reach Ratio | 1.637 mm | 1.513 mm | 1.497 mm | 1.508 mm |
| Front Center | 666 mm | 675 mm | 685 mm | 696 mm |
| Rake | 33 mm | 45 mm | 45 mm | 45 mm |
| Trail | 82 mm | 69 mm | 69 mm | 69 mm |
| Stack | 673 mm | 637 mm | 642 mm | 656 mm |
| Reach | 411 mm | 421 mm | 429 mm | 435 mm |
| Top Tube Length | 632 mm | 641 mm | 649 mm | 658 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 155 mm | 155 mm | 160 mm | 175 mm |
| Chainstay Length | 475 mm | 475 mm | 475 mm | 475 mm |
| Wheelbase | 1134 mm | 1144 mm | 1154 mm | 1165 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 800 mm | 820 mm | 850 mm | 870 mm |
| Wheels | 650 | 650 | 650 | 650 |
About this model
Sinus R5f belongs to the Winora E Sinus model. 18 e-bikes variations carry this model name so far. Take a sneak peek at all Winora E Sinus e-bikes models from 2024, by clicking here.
Model range prices
Winora Sinus Tria 9 2024 is the most economical model, with a starting price of 3070$. Winora Sinus R380 auto 2024 on the other hand costs 5082$, and is the most expensive model.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Commuter e-bikes
Our math shows that the average cost of a dependable Commuter e-bike is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2024 for 4658$. Doing a quick comparison, we notice that Sinus R5f price is 81.32% more expensive than the average cost of a Commuter e-bike.
Sinus R5f components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Sinus R5f has an aluminum fork, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
When leaving the production line, the Sinus R5f model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Sinus R5f is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
