Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Acera, Altus -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch, PowerTube, 400 Wh -
Drivetrain 1 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, GCOPD, THT, Aluminium 6061
Suspension Fork
SR Suntour, NEX E25, Steel spring, 63 mm travel, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, Acera M360
Shift Levers
Shimano, Altus M315, Rapidfire
Cassette
SunRace, CSM40, 11 - 34 teeth
Crank
Samox, 38 teeth
Bottom Bracket
integrated in the motor
Chain
KMC, X8
Chain Guide
SKS, Chainbow-E 38T
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Eco21, With Eyelets, Double Wall, Aluminium
Spokes
Stainless spokes
Tires
Schwalbe, Road Cruiser, 50-622, 28 x 2.0 inch
Brakes
Brakes
Rim
Brake Levers
Alhonga, HT474, Aluminium
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Grips
XLC, Comfort bo3
Headset
Feimin, A-Head Tapered, Ball bearing
Seat
Saddle
Selle Royal, Wave
Seatpost
XLC, Aluminium, Patent, 31.6 mm
Motor & Battery
Motor
Bosch, Active Plus, 250 W, 50 Nm, 25 km/h
Battery
Bosch, PowerTube, 400 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.592 mm | 1.553 mm | 1.603 mm | 1.566 mm | 1.53 mm |
| Stack | 643 mm | 643 mm | 667 mm | 667 mm | 667 mm |
| Reach | 404 mm | 414 mm | 416 mm | 426 mm | 436 mm |
| Top Tube Length | 620 mm | 626 mm | 626 mm | 640 mm | 648 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 210 mm | 210 mm | 210 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1140 mm | 1150 mm | 1160 mm | 1170 mm | 1180 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
Tria 8 belongs to the Winora E Tria model. Winora launched 9 e-bikes of this model so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
Winora Tria 7 eco 2024 is the cheapest e-bike model and costs 2752$. Winora Tria 10 2024 is the most expensive one and costs 3282$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter e-bikes average price
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even though the average price of a Commuter e-bike is lower, you might still be able to get a top-quality e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2024 for 2858$. Comparing this to the average Commuter e-bike price, we see that the price is 11.25% more expensive.
Tria 8 components
Fork
Winora Tria 8 2024 e-bike is equipped with the Suntour NEX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Tria 8 has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the e-bike.
Wheels
The Tria 8 2024 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Tria 8 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, you could spend a little extra and get a bike that has hydraulic brakes.
