Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset Alivio -
Suspension Hardtail -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch, PowerTube, 500 Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Winora, Aluminium 6061, GCOPD, THT, Aluminium 6061
Suspension Fork
SR Suntour, NEX E25, Steel spring, 63 mm travel, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, Alivio M3100
Shift Levers
Shimano, Alivio M3100, Trigger switch
Cassette
Shimano, HG200, 11 - 34 teeth
Crank
Samox, 38 teeth
Bottom Bracket
integrated in the motor
Chain
KMC, e9S
Chain Guide
SKS, Chainbow-E 38T
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Eco21, With Eyelets, Double Wall, Aluminium
Spokes
Stainless spokes
Tires
Schwalbe, Road Cruiser, 50-622, 28 x 2.0 inch
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT201, Aluminium
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Grips
XLC, Comfort bo3
Headset
Feimin, A-Head Tapered, Ball bearing
Seat
Saddle
Selle Royal, Wave
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Bosch, Active Plus, 250 W, 50 Nm, 25 km/h
Battery
Bosch, PowerTube, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.592 mm | 1.553 mm | 1.603 mm | 1.566 mm | 1.53 mm |
| Stack | 643 mm | 643 mm | 667 mm | 667 mm | 667 mm |
| Reach | 404 mm | 414 mm | 416 mm | 426 mm | 436 mm |
| Top Tube Length | 620 mm | 626 mm | 626 mm | 640 mm | 648 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 210 mm | 210 mm | 210 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1140 mm | 1150 mm | 1160 mm | 1170 mm | 1180 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tria 9 is part of the Winora E Tria model. 9 e-bikes variations carry this model name so far. You can get a glimpse at all models from 2024, by clicking on this link.
Model range prices
Winora Tria 7 eco 2024 is the cheapest e-bike model and costs 2752$. Winora Tria 10 2024 is the most expensive one and costs 3282$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
This e-bike was released in 2024 and its price was 3070$. Doing a quick comparison, we notice that Tria 9 price is 19.5% more expensive than the average cost of a Commuter e-bike.
Tria 9 components
Fork
Winora Tria 9 2024 e-bike is equipped with the Suntour NEX fork, and has 63mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
Tria 9 has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the e-bike.
Wheels
The Tria 9 2024 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This e-bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
