Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Travel Front 63mm -
Fork Suntour NEX
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 250W 75Nm mid-drive -
Battery Bosch, PowerTube, 500 Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
SR Suntour, NEX E25, Steel spring, travel= 63 mm, Steel steerer tube 1 1/8" - 1 1/2" tapered, Quick release 100mm
Drivetrain
Rear Derailleur
Shimano, U3020
Shift Levers
Shimano, SL-U4000
Cassette
Shimano, CS-LG300-9
Crank
Samox, 38 teeth
Bottom Bracket
integrated in the motor
Chain
KMC, e9S
Chain Guide
SKS, Chainbow-E 38T
Pedals
VP, E461, Aluminium, with Reflector
Wheels
Rims
Ryde, Eco21, with eyelets, hollow rim, Aluminium
Spokes
Sapim, Leader, Black
Tires
Schwalbe, Road Cruiser, 50-622, 28" x 2"
Brakes
Brakes
Hydraulic Disc
Brake Levers
Shimano, MT201, Aluminium,
Cockpit
Stem
aluminium, angle ajustable, A-head, 31.8 mm
Handlebar
Ergobar, oversize, 640 mm
Headset
VP, J213PE, Aluminium
Seat
Saddle
Selle Royal, Wave
Seatpost
XLC, Aluminium, Patent suspension, 31.6 mm
Motor & Battery
Motor
Bosch, Performance Line Smart System, 250W, 75 Nm
Battery
Bosch, PowerTube, 500 Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 41cm | 46cm | 51cm | 56cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.592 mm | 1.553 mm | 1.603 mm | 1.566 mm | 1.53 mm |
| Stack | 643 mm | 643 mm | 667 mm | 667 mm | 667 mm |
| Reach | 404 mm | 414 mm | 416 mm | 426 mm | 436 mm |
| Top Tube Length | 620 mm | 626 mm | 626 mm | 640 mm | 648 mm |
| Seat Tube Angle | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 180 mm | 180 mm | 210 mm | 210 mm | 210 mm |
| Chainstay Length | 480 mm | 480 mm | 480 mm | 480 mm | 480 mm |
| Wheelbase | 1140 mm | 1150 mm | 1160 mm | 1170 mm | 1180 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Tria X9 completes the Winora E Tria model. Winora launched 9 e-bikes of this model so far. Take a sneak peek at all Winora E Tria e-bikes models from 2024, by clicking here.
Model range prices
Winora Tria 7 eco 2024 is the most economical model, with a starting price of 2752$. Winora Tria 10 2024 on the other hand costs 3282$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Commuter e-bikes average price
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, you could also get a good Commuter e-bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
This e-bike was released in 2024 and its price was 3176$. Comparing the average cost of a Commuter e-bike to this one, you will see that Tria X9 price is 23.63% more expensive.
Overview of components
Fork
The Suntour NEX is included from the factory. It has a travel distance of 63mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
Tria X9 has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When it comes to wheels, the Tria X9 e-bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Winora Tria X9 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, your safety is in good hands.
