Yamaha Cross Core 2023
2023 E-bike
Estimate price |
2,399$
Weight | 19.73 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Sora -
Suspension Rigid -
Motor Yamaha 250W 70Nm mid-drive -
Battery Yamaha 500Wh with charge-life indicator and self-diagnosis display, Side-exiting dock station with anti-vibration mounting plate, Weight 6.61lb, 500Wh 36V, 4-hour charge time -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Yamaha hydroformed and butted alluminum tubing, Internal cable/housing routing, Accessory mount, Fender and Rack compatible, 3-bolt motor mount, 12 x 142 rear spacing, Integrated speed sensor harness
Suspension Fork
Alloy, 12mm thru-axle, fender compatible, internal cable housing routed, 1 1/8in steerer
Drivetrain
Rear Derailleur
Shimano Sora RD-3000 GS 9-speed
Front Derailleur
Shimano Sora (2 x 9) Braze-on
Shift Levers
Shimano 9-speed Sora trigger shifter, Gear selection window
Cassette
Shimano 9-speed, 11/30T
Crank
50/34T E-Ring 110 BCD, Square taper, 165mm (S), 170mm (M), 170mm (L)
Chain
KMC X9e
Wheels
Front Hub
Anodized. Centerlock brake mount. front hub 12 x 100 TA, rear hub 12 x 142 Shimano freehub and Yamaha Bicycles Speed Sensor
Rear Hub
Anodized. Centerlock brake mount. front hub 12 x 100 TA, rear hub 12 x 142 Shimano freehub and Yamaha Bicycles Speed Sensor
Rims
700c, Dual channel welded pin rim, Eyelet spoke holes, Width 24.5mm (OUTSIDE) 19mm (INSIDE)
Spokes
Spokes SUS304
Tires
CST Sensamo Sumo 700 x 35c Level-5 Flat Protection Reflective Sidewall approved for eBike use, PV Tube
Brakes
Brakes
Shimano Sora BL-R3000 Mechanical Disc 160mm SM-RT68 Centerlock Rotor
Cockpit
Stem
Yamaha Alloy 4-bolt faceplate, 31.8 diameter, 80mm length (53cm, 55cm), 100mm length (58cm)
Handlebar
Alloy flat bar zero degree rise, 31.8mm diameter, 640mm width
Headset
Integrated headset with 30mm headset spacers
Seat
Saddle
Yamaha Road Plus Cro-Mo Rail
Seatpost
Alloy 30.9 x 260mm (S), 315mm (M), 350mm (L) with 2-bolt adjustable tilt saddle rail clamp
Motor & Battery
Motor
PWSeries SE, Center mount, Square taper spindle, Triple Sensor System with integrated speed sensor as part of rear hub, Weight: 7.71lb, Rated power: 250W (Nominal), 500W (Max), Max torque: 70Nm, Max cadence support: 110rpm, Max speed support: 20mph Support modes: ECO+, ECO, STANDARD, HIGH
Battery
Yamaha 500Wh with charge-life indicator and self-diagnosis display, Side-exiting dock station with anti-vibration mounting plate, Weight 6.61lb, 500Wh 36V, 4-hour charge time
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.42 mm |
| Front Center | 591 mm | 603 mm | 616 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 73 mm | 66 mm | 63 mm |
| Stack | 544 mm | 551 mm | 568 mm |
| Reach | 369 mm | 388 mm | 401 mm |
| Top Tube Length | 526 mm | 546 mm | 576 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73 ° |
| Seat Tube Length | 430 mm | 463 mm | 530 mm |
| Head Tube Angle | 71 ° | 72 ° | 72.5 ° |
| Head Tube Length | 130 mm | 135 mm | 150 mm |
| Chainstay Length | 451 mm | 451 mm | 451 mm |
| Wheelbase | 1035 mm | 1047 mm | 1060 mm |
| Bottom Bracket Drop | 61 mm | 61 mm | 61 mm |
| Standover Height | 721 mm | 747 mm | 793 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
Model Overview
Cross Core completes the Yamaha E Cross model. Yamaha launched 8 e-bikes of this model so far. Take a sneak peek at all Yamaha E Cross e-bikes models from 2023, by clicking here.
Model range prices
Yamaha Cross Core 2023 is the most affordable e-bike of this model and has a price of 2399$. On the other hand, Yamaha Cross CoreRC 2023, is the most expensive and costs 2999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Hybrid e-bikes average price
If you want an acceptable Hybrid e-bike you should know that the average price is 2480$. However, this doesn’t mean that if you spend less money on a Hybrid e-bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
When Yamaha released this model in 2023, its price was 2399$. Comparing the average cost of a Hybrid e-bike to this one, you will see that Cross Core price is 3.38% lower.
Hybrid e-bikes average weight
Hybrid e-bikes weigh an average of 23.79 kg (52.45 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
With a weight of 19.73 kg (43.5 lbs), Yamaha e-bike is much lighter than average. In conclusion, the average Hybrid e-bike weighs 20.58% more than Cross Core.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
When it comes to the fork, this e-bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels
The Cross Core 2023 e-bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Cross Core has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Yamaha Cross Core e-bike has 3 sizes, in the range of 158 cm – 187 cm (5.18 ft – 6.14 ft). In short, it won’t be difficult to find the right one for you.
