Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Alivio, FSA -
Suspension Hardtail -
Motor mid-drive -
Battery 500Wh -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
159cm - 170cm
MD
165cm - 177cm
LG
171cm - 184cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
MTB Alloy 29" Internal Cable Routing
Suspension Fork
SR Suntour XCM HLO 100mm
Drivetrain
Rear Derailleur
Shimano Alivio 9sp
Front Derailleur
-
Shift Levers
Shimano Alivio
Cassette
Shimano CSHG201 9sp (11-36T)
Crank
FSA 36T-170mm
Bottom Bracket
-
Chain
Shimano HG53
Pedals
-
Wheels
Front Hub
Shimano
Rear Hub
Shimano
Rims
Alloy Double Wall
Spokes
Stainless Steel
Tires
Maxxis Forekaster TPI60 29"X2,35"
Brakes
Brakes
Front: Shimano MT200 180mm, Rear: Shimano MT200 180mm
Cockpit
Stem
BH Ahead
Handlebar
BH MTB Alloy Riser 780mm
Grips
BH Perform w/ ringlock
Headset
Tapered
Seat
Saddle
Prologo Proxim W350 Stn
Seatpost
Alloy 31,6
Motor & Battery
Motor
TS System
Battery
500Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.647 mm | 1.606 mm | 1.55 mm | 1.526 mm |
| Bottom Bracket Height | 316 mm | 316 mm | 316 mm | 316 mm |
| Stack | 657 mm | 657 mm | 662 mm | 676 mm |
| Reach | 399 mm | 409 mm | 427 mm | 443 mm |
| Top Tube Length | 594 mm | 604 mm | 623 mm | 647 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 400 mm | 450 mm | 500 mm | 520 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 140 mm | 140 mm | 145 mm | 160 mm |
| Chainstay Length | 470 mm | 470 mm | 470 mm | 470 mm |
| Wheelbase | 680 mm | 696 mm | 710 mm | 733 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 151 cm | 159 cm | 165 cm | 171 cm |
| Rider Max Height | 164 cm | 170 cm | 177 cm | 184 cm |
Model Overview
ATOM 29 belongs to the Bh E Atom model. BH launched 32 e-bikes of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
BH ATOM JET 2023 is the most affordable e-bike of this model and has a price of 2918$. On the other hand, BH ATOM LYNX 8.1 2023, is the most expensive and costs 4986$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Fitness e-bikes average price
According to our math, the average price for a trustworthy Fitness e-bike is 2351$. However, you could also get a good Fitness e-bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
This e-bike was released in 2023 and its price was 2918$. If we compare this with the average Fitness e-bike cost we notice that the price is 24.12% higher.
Internal Cable Routing
It’s also important to mention the internal cable routing that this e-bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork
The Suntour XCM is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When it comes to wheels, the ATOM 29 e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. BH ATOM 29 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
ATOM 29 comes in 4 sizes, that range from 151 cm – 184 cm (4.95 ft – 6.04 ft). In conclusion, finding one for you shouldn’t be a problem.
