Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 27.5" -
Travel Front 100mm -
Fork SunTour XCT
-
Groupset Tourney, Shimano -
Suspension Hardtail -
Drivetrain 3 × 7 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Catalyst, SmartForm C3 Alloy, 1-1/8” head tube, rack and fender mounts, 27.5"
Suspension Fork
SR Suntour XCT DS, 100mm, Coil
Drivetrain
Rear Derailleur
Shimano Tourney TX
Front Derailleur
Shimano Tourney, 31.8 clamp
Shift Levers
Shimano Rapidfire Plus, 3x7
Cassette
Sunrace, 12-34, 7-speed
Crank
Prowheel, 42/34/24
Bottom Bracket
Sealed Bearing BSA
Chain
KMC Z51, 7-speed
Pedals
Cannondale Platform
Wheels
Front Hub
Formula QR front and rear
Rear Hub
Formula QR front and rear
Rims
WTB SX19, 32h
Spokes
Stainless Steel, 14g
Tires
Freedom Transition Sport 27.5 x 2.25"
Brakes
Brakes
Tektro hydro disc, 160/160mm
Brake Levers
Tektro hydro disc
Cockpit
Stem
Cannondale Alloy, 1-1/8", 28.6, 8°
Handlebar
Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 700mm
Grips
Cannondale Dual-Density
Headset
Semi-integrated, threadless, 1-1/8"
Seat
Saddle
Cannondale Stage 2
Seatpost
Cannondale Alloy, 27.2 x 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.44 mm | 1.42 mm | 1.41 mm | 1.41 mm |
| Bottom Bracket Height | 305 mm | 305 mm | 305 mm | 305 mm | 305 mm |
| Front Center | 608 mm | 658 mm | 680 mm | 698 mm | 722 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 83 mm | 82 mm | 82 mm | 81 mm | 81 mm |
| Stack | 580 mm | 592 mm | 606 mm | 627 mm | 650 |
| Reach | 360 mm | 412 mm | 428 mm | 445 mm | 461 mm |
| Top Tube Length | 538 mm | 593 mm | 608 mm | 631 mm | 648 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73.5 ° | 73.5 ° | 74 ° |
| Seat Tube Length | 330 mm | 381 mm | 432 mm | 482 mm | 533 mm |
| Head Tube Angle | 69.5 ° | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 90 mm | 100 mm | 115 mm | 135 mm | 160 mm |
| Chainstay Length | 433 mm | 433 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1037 mm | 1087 mm | 1109 mm | 1127 mm | 1152 mm |
| Bottom Bracket Drop | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Standover Height | 674 mm | 708 mm | 747 mm | 789 mm | 831 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Catalyst 2 completes the Cannondale Catalyst model. There are 12 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Model range prices
Cannondale Catalyst 3 2019 is the most affordable bike of this model and has a price of 460$. On the other hand, Cannondale Catalyst 1 2019, is the most expensive and costs 630$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
Our math shows that the average cost of a dependable Crosscountry bike is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Cannondale Catalyst 2 price was 525$. If we compare this with the average Crosscountry bike cost we notice that the price is 262.86% smaller.
Overview of components
Fork
The Catalyst 2 comes factory-installed with the SunTour XCT fork. This has a travel range of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
As for the wheels, Cannondale Catalyst 2 2019, has a 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Cannondale Catalyst 2 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Catalyst 2 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
