Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Sora, FSA -
Suspension Rigid -
Drivetrain 2 × 9 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
DB Alternative Road, Disc Brake, Endurance Geometry, Relaxed Head Tube Angle, Fully Butted 6061-T6 Aluminum Formed Top Tube, Tapered Headtube, Flat Mount Disc, Replaceable Hanger
Suspension Fork
DB SPF Formed Aluminum Gravel Disc w/1.5" Tapered Steerer Tube
Drivetrain
Rear Derailleur
Shimano Sora RD-R3000, 9 Speed, GS
Front Derailleur
Shimano Sora FD-R3000, 31.8 Band Clamp
Shift Levers
Shimano Sora ST-R3000, 2x9 Speed
Cassette
Shimano HG400, 9 Speed Cassette, 11-32T
Crank
FSA Omega Adventure, 46/30T
Bottom Bracket
FSA Mega Exo
Chain
KMC Z9, 9 Speed
Pedals
DB Resin Gravel Platform
Wheels
Front Hub
28h Aluminum Quick Release
Rear Hub
28h Aluminum Quick Release, Cassette
Rims
Diamondback Equation CX, 28h, Doublewall
Spokes
14g Stainless Steel
Tires
WTB Riddler Comp, 700x37c
Brakes
Brakes
Tektro Lyra Flat Mount Mechanical Disc, w/160mm Front / 160mm Rear Rotors
Brake Levers
Shimano Sora ST-R3000
Cockpit
Stem
HED, 6061 Aluminum 3D Forged, +/-7° Rise, 31.8 Bar Bore
Handlebar
HED, 7050 Aluminum 12 Degree Flare, 31.8mm Bar Bore
Grips
Diamondback Endurance Gel Tape
Headset
FSA No.42B, Sealed Cartridge
Seat
Saddle
Diamondback Performance Gravel Road
Seatpost
HED, 6061 Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.45 mm | 1.57 mm | 1.6 mm | 1.6 mm |
| Bottom Bracket Height | 280 mm | 280 mm | 280 mm | 280 mm | 280 mm |
| Front Center | 603 mm | 599 mm | 611 mm | 611 mm | 631 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 79 mm | 106 mm | 74 mm | 95 mm | 97 mm |
| Stack | 531 mm | 541 mm | 571 mm | 600 mm | 624 mm |
| Reach | 376 mm | 374 mm | 364 mm | 375 mm | 389 mm |
| Top Tube Length | 520 mm | 520 mm | 535 mm | 555 mm | 575 mm |
| Seat Tube Angle | 75 ° | 75 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 395 mm | 475 mm | 505 mm | 535 mm | 565 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 105 mm | 120 mm | 155 mm | 175 mm | 200 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1028 mm | 1034 mm | 1036 mm | 1036 mm | 1057 mm |
| Bottom Bracket Drop | 70 mm | 0 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 696 mm | 722 mm | 771 mm | 806 mm | 840 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Haanjo 3 is a Diamondback Haanjo model. 60 bikes variations carry this model name so far. Take a sneak peek at all Diamondback Haanjo bikes models from 2022, by clicking here.
Model range prices
Diamondback Haanjo 1 2022 is the cheapest bike model and costs 785$. Diamondback Haanjo 8C Carbon 2022 is the most expensive one and costs 4650$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Gravel bikes
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
This bike was released in 2022 and its price was 1175$. Doing a quick comparison, we notice that Haanjo 3 price is 109.53% lower than the average cost of a Gravel bike.
Haanjo 3 components
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Wheels size
As for the wheels, Diamondback Haanjo 3 2022, has a 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
When you want to stop the bike in time, the brakes are vital. The Haanjo 3 has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Haanjo 3 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
