flyer Upstreet3 7.23 High 2023
2023 E-bike
Estimate price |
6,688$
Weight | 31 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Panasonic 90Nm mid-drive -
Battery FLYER SIB-750 (750 Wh / 20.1 Ah / 36 V) -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 179cm
LG
177cm - 188cm
XL
186cm - 197cm
XXL
195cm - 206cm
XXXL
204cm - 214cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Hydroformed Tubing
Suspension Fork
SR Suntour MobiE 45 Air, 60 mm Travel, 15 x 100 mm Axle
Drivetrain
Cassette
Enviolo TR; Gates Carbon Drive CDX
Pedals
FLYER Wellgo
Wheels
Front Hub
Bear Pawls BMT-003, 36h
Rear Hub
Enviolo TR CVP, 36h
Rims
Mach1 Trucky
Tires
Schwalbe Super Moto 27.5 x 2.4
Brakes
Brakes
Magura MT5, 203/180 mm
Cockpit
Stem
Satori All Up 1.5", 35 x 95 mm, Adjustable Height 90 mm (S-M) 150 mm (L-XXXL), Adjustable Angle
Handlebar
FLYER Cruise, 640 mm, 42°, 55 mm
Seat
Saddle
Selle Royal Viaggio
Seatpost
bySchulz G.2 ST, 31.6 mm x 350 mm (S-M) / 31.6 x 400 mm (L-XL) / 31.6 x 450 mm ( XXL-XXXL)
Motor & Battery
Motor
Panasonic GX Ultimate (90 Nm)
Battery
FLYER SIB-750 (750 Wh / 20.1 Ah / 36 V)
Charger
FLYER Fast Charger 6A 36V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL | XXXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.67 mm | 1.64 mm | 1.61 mm | 1.6 mm | 1.59 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 657 mm | 657 mm | 677 mm | 703 mm | 723 mm | 744 mm |
| Rake | 44 mm | 45 mm | 44 mm | 45 mm | 43 mm | 43 mm |
| Trail | 80 mm | 72 mm | 70 mm | 69 mm | 71 mm | 71 mm |
| Stack | 623 mm | 646 mm | 667 mm | 686 mm | 705 mm | 724 mm |
| Reach | 384 mm | 387 mm | 406 mm | 425 mm | 440 mm | 454 mm |
| Top Tube Length | 576 mm | 586 mm | 611 mm | 636 mm | 656 mm | 676 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm | 590 mm | 630 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm | 230 mm |
| Chainstay Length | 488 mm | 488 mm | 488 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1140 mm | 1140 mm | 1160 mm | 1186 mm | 1206 mm | 1227 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 160 cm | 168 cm | 177 cm | 186 cm | 195 cm | 204 cm |
| Rider Max Height | 170 cm | 179 cm | 188 cm | 197 cm | 206 cm | 214 cm |
About this model
Upstreet3 7.23 High completes the Flyer E Upstreet3 model. There are 8 e-bikes that carry this model name. Take a sneak peek at all Flyer E Upstreet3 e-bikes models from 2023, by clicking here.
Model range prices
Flyer Upstreet3 7.10 High 2023 is the cheapest e-bike model and costs 5467$. Flyer Upstreet3 7.23 HS EU Low 2023 is the most expensive one and costs 6847$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Commuter e-bikes average price
According to our calculations, the average cost of a Commuter e-bike that is reliable is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. In conclusion, always check e-bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 6104$. Comparing the average cost of a Commuter e-bike to this one, you will see that Upstreet3 7.23 High price is 137.6% more expensive.
Commuter e-bikes average weight
Commuter e-bikes weigh an average of 24.02 kg (52.95 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
With a weight of 31 kg (68.34 lbs), Flyer e-bike is much heavier than average. To sum up, it’s 29.06% heavier than the average weight of Commuter e-bikes.
Overview of components
Fork
This e-bike has the Suntour MOBIE fork installed. The fork’s travel is 60mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
The wheels on Upstreet3 7.23 High are the aluminum type. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, they don’t perform so well when you go over bumps and obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Flyer Upstreet3 7.23 High has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Upstreet3 7.23 High comes in 6 sizes, that range from 160 cm – 214 cm (5.25 ft – 7.02 ft). In short, you can easily find one that suits you.
