flyer Upstreet3 7.23 HS EU High 2023
2023 E-bike
Estimate price |
7,502$
Weight | 31 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 60mm -
Fork Suntour MOBIE
-
Suspension Hardtail -
Motor Panasonic 90Nm mid-drive -
Battery FLYER SIB-750 (750 Wh / 20.1 Ah / 36 V) -
Drivetrain Internally Geared Hub -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 170cm
MD
168cm - 179cm
LG
177cm - 188cm
XL
186cm - 197cm
XXL
195cm - 206cm
XXXL
204cm - 214cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FLYER Engineered, Hydroformed Tubing
Suspension Fork
SR Suntour MobiE 45 Air, 60 mm Travel, 15 x 100 mm Axle
Drivetrain
Cassette
Enviolo TR; Gates Carbon Drive CDX, Option: Enviolo TR Automatiq Integrated; Gates Carbon Drive CDX (EUR 300.00)
Pedals
FLYER Wellgo
Wheels
Front Hub
Bear Pawls BMT-003, 36h
Rear Hub
Enviolo TR CVP, 36h
Rims
Mach1 Trucky
Tires
Schwalbe Super Moto 27.5 x 2.4
Brakes
Brakes
Magura MT5e, 203/180 mm
Cockpit
Stem
Satori All Up 1.5", 35 x 95 mm, Adjustable Height 90 mm (S-M) 150 mm (L-XXXL), Adjustable Angle
Handlebar
FLYER Cruise, 640 mm, 42°, 55 mm
Seat
Saddle
Selle Royal Viaggio
Seatpost
bySchulz G.2 ST, 31.6 mm x 350 mm (S-M) / 31.6 x 400 mm (L-XL) / 31.6 x 450 mm ( XXL-XXXL)
Motor & Battery
Motor
Panasonic GX Ultimate HS (90 Nm)
Battery
FLYER SIB-750 (750 Wh / 20.1 Ah / 36 V)
Charger
FLYER Fast Charger 6A 36V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL | XXXL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.67 mm | 1.64 mm | 1.61 mm | 1.6 mm | 1.59 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm | 299 mm |
| Front Center | 657 mm | 657 mm | 677 mm | 703 mm | 723 mm | 744 mm |
| Rake | 44 mm | 45 mm | 44 mm | 45 mm | 43 mm | 43 mm |
| Trail | 80 mm | 72 mm | 70 mm | 69 mm | 71 mm | 71 mm |
| Stack | 623 mm | 646 mm | 667 mm | 686 mm | 705 mm | 724 mm |
| Reach | 384 mm | 387 mm | 406 mm | 425 mm | 440 mm | 454 mm |
| Top Tube Length | 576 mm | 586 mm | 611 mm | 636 mm | 656 mm | 676 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 430 mm | 470 mm | 510 mm | 550 mm | 590 mm | 630 mm |
| Head Tube Angle | 69 ° | 70 ° | 70.5 ° | 70.5 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm | 190 mm | 210 mm | 230 mm |
| Chainstay Length | 488 mm | 488 mm | 488 mm | 488 mm | 488 mm | 488 mm |
| Wheelbase | 1140 mm | 1140 mm | 1160 mm | 1186 mm | 1206 mm | 1227 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 160 cm | 168 cm | 177 cm | 186 cm | 195 cm | 204 cm |
| Rider Max Height | 170 cm | 179 cm | 188 cm | 197 cm | 206 cm | 214 cm |
About this model
Upstreet3 7.23 HS EU High is part of the Flyer E Upstreet3 model. There are 8 e-bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Flyer Upstreet3 7.10 High 2023 is the most affordable e-bike of this model and has a price of 5467$. On the other hand, Flyer Upstreet3 7.23 HS EU Low 2023, is the most expensive and costs 6847$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Commuter e-bikes
If you want to purchase a solid Commuter e-bike, it is important to know that the average cost is 2569$. However, even if your budget is less than the average, you might still be able to get a top-quality Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Flyer Upstreet3 7.23 HS EU High price was 6847$. In conclusion, this e-bike price is 166.52% more expensive than the price of the average Commuter e-bike.
Average weight for Commuter e-bikes
On a deeper look, we notice that the average weight of a Commuter e-bike is 24.02 kg (52.95 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Flyer Upstreet3 7.23 HS EU High it’s weighing 31 kg (68.34 lbs). At this weight, is much heavier than average. To sum up, it’s 29.06% heavier than the average weight of Commuter e-bikes.
Upstreet3 7.23 HS EU High components
Fork
The Upstreet3 7.23 HS EU High comes factory-installed with the Suntour MOBIE fork. This has a travel range of 60mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
When leaving the production line, the Upstreet3 7.23 HS EU High model has aluminum wheels. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Upstreet3 7.23 HS EU High comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Upstreet3 7.23 HS EU High comes in 6 sizes, that range from 160 cm – 214 cm (5.25 ft – 7.02 ft). In short, you can easily find one that suits you.
