Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Judy Silver TK
-
Groupset Deore, FSA -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 175cm
MD
173cm - 180cm
LG
178cm - 185cm
XL
173cm - 193cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Fuji A2-SL custom-butted alloy, sealed cartridge bearing pivots, A4 suspension, Boost 148x12mm, 120mm
Suspension Fork
RockShox Judy Silver TK 29 Solo Air, tapered alloy steerer, Boost 110x15mm, 120mm
Rear Shock
RockShox Deluxe Select+ RL
Drivetrain
Rear Derailleur
Shimano Deore, shadow plus
Front Derailleur
N/A
Shift Levers
Shimano Deore, Rapid Fire, 1 x 10-speed
Cassette
Shimano HG-500, 11-42T
Crank
FSA Gamma Pro, 30T
Bottom Bracket
FSA Mega EXO, threaded
Chain
KMC X10
Pedals
Alloy platform
Wheels
Rims
WTB STP i25 TCS 2.0 32H rims, Formula DC-511 front, DC-1248 rear hub, stainless black spokes
Tires
Maxxis Ardent, 29" x 2.40", 60tpi, EXO, Tubeless Ready, folding, Maxxis Ardent, 29" x 2.25", 60tpi, EXO, Tubeless Ready, folding
Brakes
Brakes
Shimano MT200, 180/160mm rotors
Brake Levers
Shimano MT200
Cockpit
Stem
Oval Concepts 600AM, alloy, 0°
Handlebar
Oval Concepts 205 riser bar, 6061 alloy, ± 5mm rise, 760mm
Grips
Fuji Performance Grip Lock On
Headset
FSA 1 1/8" - 1.5", sealed bearings
Seat
Saddle
WTB Volt Sport
Seatpost
Oval Concepts, alloy, 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.36 mm | 1.31 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 339 mm | 339 mm | 339 mm |
| Front Center | 697 mm | 723 mm | 749 mm | 770 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 96 mm | 96 mm | 96 mm | 96 mm |
| Stack | 588.9 mm | 598.1 mm | 607.4 mm | 616.7 mm |
| Reach | 418 mm | 440.4 mm | 462.8 mm | 480.3 mm |
| Top Tube Length | 581 mm | 606 mm | 631 mm | 651 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 401 mm | 432 mm | 486.2 mm | 536.3 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 90 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1134 mm | 1160 mm | 1186 mm | 1207 mm |
| Bottom Bracket Drop | 35 mm | 35 mm | 35 mm | 35 mm |
| Standover Height | 797 mm | 802 mm | 815 mm | 838 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 165 cm | 173 cm | 178 cm | 173 cm |
| Rider Max Height | 175 cm | 180 cm | 185 cm | 193 cm |
About this model
Outland 29 1.1 completes the Fuji Outland model. Fuji launched 69 bikes of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
The most economical model, the Fuji Outland 29 1.3 2020 has a starting price of 1299$. Fuji Outland 29 1.0 2020 on the other hand is the most expensive at 2299$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, this bike was made available in 2020 for 1799$. If we compare this with the average Trail bike cost we notice that the price is 53.53% smaller.
Outland 29 1.1 components
Fork
The RockShox Judy Silver TK is included from the factory. It has a travel distance of 120mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
As for the rear shock, this bike has the RockShox Deluxe Select+ RL model, with a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
When leaving the production line, the Outland 29 1.1 model has 29″ aluminum wheels. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Fuji Outland 29 1.1 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 165 cm – 193 cm (5.41 ft – 6.33 ft). In conclusion, it won’t take much to find one that’s right for you.
