Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 145mm -
Travel Rear 125mm -
Fork Fox Float 32
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX SL-Grade Aluminum, 5" Maestro Suspension
Suspension Fork
Fox 32 Talas Evolution 26" CTD w/ 15QR thru-axle, OverDrive 2, 125-145mm Travel
Rear Shock
Fox Float CTD Boostvalve
Drivetrain
Rear Derailleur
Shimano Deore XT Shadow Plus
Front Derailleur
Shimano SLX
Shift Levers
Shimano SLX, 2x10 Speed
Cassette
Shimano HG81 11x36, 10-Speed
Crank
Shimano Deore XT, 26/38
Bottom Bracket
Shimano, Press Fit
Chain
KMC X10
Pedals
N/A
Wheels
Front Hub
[F] Giant Tracker Sealed/CNC w/ 15mm Axle, [R] Giant Tracker Performance, 32h
Rear Hub
[F] Giant Tracker Sealed/CNC w/ 15mm Axle, [R] Giant Tracker Performance, 32h
Rims
Giant P-XC 2, Double Wall
Spokes
DT Swiss Competition, 14/15g
Tires
Schwalbe Racing Ralph, 26x2.25 EVO Folding TL Ready
Brakes
Brakes
Shimano SLX, [F] 180mm, [R] 160mm
Brake Levers
Shimano SLX
Cockpit
Stem
Giant Connect SL, OverDrive 2
Handlebar
Giant Connect SL, Low Rise, 31.8
Seat
Saddle
Fi'zi:k Vesta w/ Manganese Rails
Seatpost
Giant Contact Switch w/ Remote, 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Top Tube Length | 536 mm | 551 mm | 564 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73.5 ° |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 124 mm | 135 mm | 150 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1062 mm | 1072 mm | 1087 mm |
| Standover Height | 691 mm | 706 mm | 739 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
Model Overview
Trance X1 W belongs to the Giant Trance model. There are 139 bikes that carry this model name. Check out the entire range from 2013 of this model, by clicking this link.
Model range prices
Giant Trance X3 2013 is the most affordable bike of this model and has a price of 1550$. On the other hand, Giant Trance X 29er 0 2013, is the most expensive and costs 4250$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 3200$. Comparing this to the average Trail bike price, we see that the price is 15.86% higher.
Overview of components
Fork
The Fox Float 32 is included from the factory. It has a travel distance of 145mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In short, you should always ensure you have a good fork when purchasing a bike.
Rear Shock
The shock that’s installed on this bike is Fox Float CTD Boostvalve, with a travel distance of 125mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
The wheels on Trance X1 W are the 26″ aluminum type. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Trance X1 W comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Giant Trance X1 W bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, it won’t be difficult to find the right one for you.
Dropper post
The Giant model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
