Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork Fox Performance Float 34
-
Groupset SLX -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon Fiber
Suspension Fork
Fox Float 34 Performance Series, Step-Cast, Grip, 120mm, 29’, 110x15
Drivetrain
Rear Derailleur
Shimano SLX M7100 Shadow Plus
Shift Levers
Shimano SLX M7100
Cassette
Shimano SLX, 10-51T
Crank
Shimano SLX M7120 24mm spindle, 30t Alloy RingS/M: 170mm, L/XL: 175mm
Bottom Bracket
Shimano SLX BB52
Chain
Shimano SLX M7100
Chain Guide
Ibis Top Guide
Wheels
Rims
Ibis 933 Aluminum Rims, Ibis Hubs
Tires
Maxxis Recon Race 29" x 2.4" Exo/TR WT
Brakes
Brakes
Shimano SLX M7100
Cockpit
Stem
Ibis 31.8mmS/M: 40mm, L/XL: 50mm
Handlebar
Ibis 800mm Carbon; Lo-Fi (S–M), Hi Fi Bar (L–XL)
Grips
Lizard Skin Charger Evo
Headset
Cane Creek 40: IS 41/28.6 upper, IS 52/40 lower
Seat
Saddle
WTB Silverado
Seatpost
Bike Yoke Revive DropperS: 125mm, M: 160mm, L: 185mm, XL/XXL: 213mm. Note there is a 250lb rider weight limit on this post.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.42 mm | 1.35 mm | 1.28 mm |
| Bottom Bracket Height | 308 mm | 308 mm | 308 mm | 308 mm |
| Front Center | 683 mm | 728 mm | 769 mm | 820 mm |
| Rake | 34 mm | 44 mm | 44 mm | 44 mm |
| Trail | 114 mm | 114 mm | 114 mm | 114 mm |
| Stack | 622 mm | 629 mm | 642 mm | 665 mm |
| Reach | 411 mm | 442 mm | 477 mm | 518 mm |
| Top Tube Length | 587 mm | 615 mm | 647 mm | 682 mm |
| Seat Tube Angle | 74 ° | 74.5 ° | 75 ° | 76 ° |
| Seat Tube Length | 356 mm | 406 mm | 457 mm | 508 mm |
| Head Tube Angle | 66.5 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 85 mm | 95 mm | 110 mm | 135 mm |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1107 mm | 1152 mm | 1193 mm | 1244 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 700 | 721 mm | 769 mm | 783 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
DV9 V2 SLX belongs to the Ibis Dv9 model. There are 24 bikes that carry this model name. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Ibis DV9 V2 GX 2023 is the most economical model, with a starting price of 3499$. Ibis DV9 V2 XX SL 2023 on the other hand costs 8699$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2023 for 3999$. If we compare this with the average Trail bike cost we notice that the price is 44.79% more expensive.
DV9 V2 SLX components
Fork
The DV9 V2 SLX comes factory-installed with the Fox Performance Float 34 fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels
As for the wheels, Ibis DV9 V2 SLX 2023, has a 29″ aluminum model. With 29″ wheels, bumps will feel lighter and you’ll gain more speed on descends, compared to smaller wheel-sized bikes. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Ibis DV9 V2 SLX has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Ibis DV9 V2 SLX bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
