Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Rhythm Float 34
-
Groupset XT, SLX -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 140mm Travel
Suspension Fork
Fox Rhythm 34 Float Air 140mm Tapered 110mm Spacing
Rear Shock
Fox Performance Float DPS
Drivetrain
Rear Derailleur
Shimano XT
Front Derailleur
n/a
Shift Levers
Shimano SLX
Cassette
Shimano SLX 11-42t 11spd
Crank
30t Narrow/wide
Bottom Bracket
RaceFace PF92
Chain
KMC X11-1
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Shimano SLX 110x15mm
Rear Hub
Shimano SLX 148x12mm
Rims
WTB STP i29 TCS
Spokes
Stainless Black 15g
Tires
Maxxis Tomahawk EXO TR 27.5x2.3"
Brakes
Brakes
Shimano SLX
Brake Levers
Shimano SLX
Disk Rotors
Shimano SLX 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp (Volt 250 Comp size S)
Seatpost
KS Lev Integra w/Southpaw Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.49 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 661 mm | 685 mm | 714 mm | 742 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 95 mm | 97 mm | 98 mm | 98 mm |
| Stack | 588 mm | 597 mm | 606 mm | 616 mm |
| Reach | 381 mm | 401 mm | 426 mm | 451 mm |
| Top Tube Length | 539 mm | 562 mm | 590 mm | 618 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 345 mm | 370 mm | 420 mm | 470 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1087 mm | 1108 mm | 1136 mm | 1165 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 692 mm | 713 mm | 752 mm | 791 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm |
About this model
Hei Hei Trail belongs to the Kona Hei model. There are 58 bikes that carry this model name. You can easily view all of the Kona Hei bikes models from 2017, here.
Model range prices
Kona Hei Hei 2017 is the most affordable bike of this model and has a price of 2499$. On the other hand, Kona Hei Hei Supreme 2017, is the most expensive and costs 7999$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 4199$. Comparing this to the average Trail bike price, we see that the price is 52.03% higher.
Overview of components
Fork
The fork installed on this bike is the Fox Rhythm Float 34 model. The travel on this model is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Rear Shock
Kona Hei Hei Trail bike has the Fox Performance Float DPS model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Hei Hei Trail bike is equipped with the 27.5″ aluminum model. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hei Hei Trail comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
The Kona model is also equipped with a dropper post. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
