Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 140mm -
Fork Fox Factory Float 34
-
Groupset XTR -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
147cm - 154cm
SM
152cm - 170cm
MD
157cm - 182cm
LG
175cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Kona Race Light Carbon 140mm Travel
Suspension Fork
Fox Factory 34 Float Air 140mm Tapered 110mm Spacing
Rear Shock
Fox Factory Float DPS
Drivetrain
Rear Derailleur
Shimano XTR
Front Derailleur
n/a
Shift Levers
Shimano XT
Cassette
Shimano XT 11-42t 11spd
Crank
30t Narrow/wide
Bottom Bracket
Shimano PF92
Chain
KMC X11-1
Chain Guide
n/a
Pedals
n/a
Wheels
Front Hub
Hope Pro4 110x15mm
Rear Hub
Hope Pro4 148x12mm
Rims
WTB Ci31 TCS
Spokes
Stainless Black 15g
Tires
Maxxis Tomahawk EXO TR 27.5x2.3"
Brakes
Brakes
Shimano XT
Brake Levers
Shimano XT
Disk Rotors
Shimano RT66 180mm
Cockpit
Stem
Kona XC/BC 35
Handlebar
Kona XC/BC 35 Riser
Grips
ODI Ruffian MX
Headset
FSA No.57B
Seat
Saddle
WTB Volt Comp (Volt 250 Comp size S)
Seatpost
KS Lev Integra w/Southpaw Lever 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG |
|---|---|---|---|---|
| Stack Reach Ratio | 1.54 mm | 1.49 mm | 1.42 mm | 1.37 mm |
| Bottom Bracket Height | 338 mm | 338 mm | 338 mm | 338 mm |
| Front Center | 661 mm | 685 mm | 714 mm | 742 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 95 mm | 97 mm | 98 mm | 98 mm |
| Stack | 588 mm | 597 mm | 606 mm | 616 mm |
| Reach | 381 mm | 401 mm | 426 mm | 451 mm |
| Top Tube Length | 539 mm | 562 mm | 590 mm | 618 mm |
| Seat Tube Angle | 75 ° | 75 ° | 75 ° | 75 ° |
| Seat Tube Length | 345 mm | 370 mm | 420 mm | 470 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm | 135 mm |
| Chainstay Length | 421 mm | 421 mm | 421 mm | 421 mm |
| Wheelbase | 1087 mm | 1108 mm | 1136 mm | 1165 mm |
| Bottom Bracket Drop | 17 mm | 17 mm | 17 mm | 17 mm |
| Standover Height | 692 mm | 713 mm | 752 mm | 791 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 147 cm | 152 cm | 157 cm | 175 cm |
| Rider Max Height | 154 cm | 170 cm | 182 cm | 195 cm |
Model Overview
Hei Hei Trail DL completes the Kona Hei model. 58 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Model range prices
Kona Hei Hei 2017 is the most affordable bike of this model and has a price of 2499$. On the other hand, Kona Hei Hei Supreme 2017, is the most expensive and costs 7999$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Kona released this model in 2017, its price was 5999$. Comparing this to the average Trail bike price, we see that the price is 117.2% more expensive.
Overview of components
Fork
The fork installed on this bike is the Fox Factory Float 34 model. The travel on this model is 140mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Kona Hei Hei Trail DL bike has the Fox Factory Float DPS model installed, and has a travel of 140mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Hei Hei Trail DL bike is equipped with the 27.5″ aluminum model. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Hei Hei Trail DL comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 147 cm – 195 cm (4.82 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
Kona Hei Hei Trail DL includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
