Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 20" -
Groupset Altus, Shimano -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
One Size
115cm - 130cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ALUXX-Grade Aluminum
Suspension Fork
alloy, rigid
Rear Shock
N/A
Drivetrain
Rear Derailleur
Shimano Altus RD-M310
Front Derailleur
N/A
Shift Levers
Shimano REVOSHIFT, 1x7
Cassette
Shimano CS-HG200, 12x32
Crank
alloy forged, 30t, 127mm
Bottom Bracket
cartridge
Chain
KMC Z7
Pedals
platform
Wheels
Front Hub
Giant Disc, 28h, QR, alloy, disc
Rear Hub
Giant Disc, 28h, QR, alloy, disc
Rims
Giant 20", alloy, 28mm inner width
Spokes
stainless, 14g
Tires
Kenda Karma, 20x2.6"
Brakes
Brakes
mechanical disc [F]160mm, [R]160mm rotors
Brake Levers
alloy, junior
Cockpit
Stem
forged alloy, 0-degree
Handlebar
Giant Sport, alloy, 31.8mm
Grips
Giant Junior
Seat
Saddle
Giant Jr. Sport
Seatpost
alloy, 27.2x250mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | One Size |
|---|---|
| Stack Reach Ratio | 1.44 mm |
| Front Center | 523 mm |
| Rake | 42 mm |
| Trail | 59.8 mm |
| Stack | 444 mm |
| Reach | 309 mm |
| Top Tube Length | 446 mm |
| Seat Tube Angle | 73 ° |
| Seat Tube Length | 260 mm |
| Head Tube Angle | 69 ° |
| Head Tube Length | 105 mm |
| Chainstay Length | 361 mm |
| Wheelbase | 883 mm |
| Bottom Bracket Drop | 20 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 130 cm |
Model Overview
STP 20 Liv is part of the Liv Stp model. Liv released 12 bikes variations of this model so far. Check out the entire range from 2022 of this model, by clicking this link.
Model range prices
Liv STP 20 FS Liv 2022 is the most affordable bike of this model and has a price of 445$. On the other hand, Liv STP 26 Liv 2022, is the most expensive and costs 955$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Youth bikes average price
According to our math, the average price for a trustworthy Youth bike is 278$. However, even if your budget is less than the average, you might still be able to get a top-quality Youth bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 535$. In conclusion, this bike price is 92.45% higher than the price of the average Youth bike.
STP 20 Liv components
Fork material
STP 20 Liv has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Wheels
When leaving the production line, the STP 20 Liv model has 20″ aluminum wheels. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The STP 20 Liv has Mechanical Disc brakes. They deliver good performance and cost less than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
This bike has one size only, so it might not fit you. In short, make sure you double-check if it fits you.
