Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Tiagra, FSA -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Series 3 Beyond Road, 6061 Aluminum, Tapered Head Tube, Relieved BB, Internal Cable Routing, Flat-Mount Disc, 142x12mm Thru-Axle
Suspension Fork
Marin Full Carbon w/ Taper Steerer, 12mm Thru-Axle, Flat-Mount Disc, Fender Eyelets
Drivetrain
Rear Derailleur
Shimano Tiagra 10-Speed
Front Derailleur
Shimano Tiagra
Shift Levers
Shimano Tiagra 2x10-Speed
Cassette
Shimano Tiagra HG-500, 11-34T
Crank
FSA Gossamer, MegaExo Spindle, 50/34T
Bottom Bracket
FSA MegaExo Threaded
Chain
KMC X10
Pedals
Commute Platform
Wheels
Front Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rear Hub
Forged Aluminum Alloy, 6-Bolt Disc, 32H
Rims
Marin Aluminum Double Wall, 19mmInner, 24mm Tall, Disc Specific, TubelessCompatible
Spokes
14g Black Stainless Steel
Tires
WTB, Exposure Comp, 700Cx32, Wire Bead
Brakes
Brakes
Tektro MD-C500 Dual Piston Road Mechanical Disc, 160mm Rotor
Brake Levers
Shimano w/ Integrated Shifters
Cockpit
Stem
Marin 3D Forged Alloy
Handlebar
Marin Butted Alloy, Compact 12º Flared Drop
Grips
Marin Perforated Tape
Headset
FSA Orbit IS, Sealed Cartridge Bearings, 11/8”x11/2”
Seat
Saddle
Marin Beyond Road Concept
Seatpost
Marin Alloy
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.05 mm | 1.53 mm | 1.52 mm | 1.54 mm | 1.56 mm |
| Bottom Bracket Height | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm | 271 mm |
| Front Center | 589 mm | 590 mm | 595 mm | 615 mm | 630 mm | 640 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 67 mm | 222 mm | 61 mm | 61 mm | 61 mm | 58 mm |
| Stack | 544.5 mm | 562.4 mm | 576.7 mm | 595.7 mm | 614.7 mm | 635.8 mm |
| Reach | 371.6 mm | 537 mm | 376.8 mm | 391.1 mm | 399.7 mm | 408.2 mm |
| Top Tube Length | 522 mm | 537 mm | 547 mm | 567 mm | 587 mm | 602 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 470 mm | 490 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 71 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72.5 ° |
| Head Tube Length | 120 mm | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm | 417 mm |
| Wheelbase | 995 mm | 996 mm | 1001 mm | 1021 mm | 1036 mm | 1046 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 715 mm | 734 mm | 753 mm | 776 mm | 795 mm | 815 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
Model Overview
Gestalt 2 is a Marin Gestalt model. There are 42 bikes that carry this model name. You can get a glimpse at all models from 2019, by clicking on this link.
Model range prices
The most economical model, the Marin Gestalt 2019 has a starting price of 829$. Marin Gestalt X11 2019 on the other hand is the most expensive at 2199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Gravel bike. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
When Marin released this model in 2019, its price was 1299$. In conclusion, this bike price is 89.53% smaller than the price of the average Gravel bike.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When it comes to wheels, the Gestalt 2 bike is equipped with the 700c aluminum model. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Marin Gestalt 2 has Mechanical Disc brakes installed. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
