Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Travel Rear 100mm -
Fork RockShox 30 Silver TK
-
Groupset SLX, Deore -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Faze 29er aluminum 100 mm travel frame
Suspension Fork
Rockshox 30 Gold TK 100 mm travel
Rear Shock
Fox Float CTD Evolution
Drivetrain
Rear Derailleur
Shimano SLX RD 10 speed
Front Derailleur
Shimano Deore 10 speed front derailleur
Shift Levers
Jagwire LEX housing
Cassette
Shimano Deore 10 speed cassette
Crank
Shimano FC M552 2 pc 10 speed 42/32/22T
Bottom Bracket
N/A
Chain
SRAM PC 1031 10 speed
Chain Tensioner
N/A
Pedals
Wellgo alloy body / steel cage MTB pedal
Wheels
Front Hub
SRAM Front loose ball hub
Rear Hub
SRAM rear 135 x 10 w/ QR axle
Rims
Alex MD-17 29er rim
Tires
Schwalbe Smart Sam 29 x 2.1 tire
Brakes
Brakes
Shimano Deore BR-M615 hydraulic brake w/ 160 mm rotor
Brake Levers
N/A
Disk Rotors
N/A
Cockpit
Stem
Alloy MTB stem with 4 bolt front clamp
Handlebar
Norco 15 mm rise 680-720 mm width 6061 bar
Grips
T-One Single side lock on grip
Headset
FSA # 10 headset internal 50 OD / 44 ID
Seat
Saddle
Norco MTB XC Trail saddle
Seatpost
Norco 6061 alloy double bolt head 30.9 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.462 mm | 1.407 mm | 1.357 mm | 1.304 mm |
| Bottom Bracket Height | 327.5 mm | 327.5 mm | 327.5 mm | 327.5 mm |
| Front Center | 667 mm | 690 mm | 703 mm | 727 mm |
| Rake | 51 mm | 51 mm | 46 mm | 46 mm |
| Trail | 82 mm | 82 mm | 84 mm | 84 mm |
| Stack | 598 mm | 605 mm | 612 mm | 618 mm |
| Reach | 409 mm | 430 mm | 451 mm | 474 mm |
| Top Tube Length | 575 mm | 598 mm | 621 mm | 645 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 400 mm | 445 mm | 490 mm | 535 mm |
| Head Tube Angle | 70 ° | 70 ° | 70.5 ° | 70.5 ° |
| Head Tube Length | 100 mm | 107 mm | 110 mm | 117 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1108 mm | 1132 mm | 1144 mm | 1169 mm |
| Bottom Bracket Drop | 43 mm | 43 mm | 43 mm | 43 mm |
| Standover Height | 789 mm | 774 mm | 781 mm | 793 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Rear Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Faze 9.2 is part of the Norco Faze model. Norco launched 22 bikes of this model so far. You can get a glimpse at all models from 2014, by clicking on this link.
Model range prices
Norco Faze 9.3 2014 is the cheapest bike model and costs 1315$. Norco Faze 9.1 2014 is the most expensive one and costs 2330$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2014, its price was 1815$. Doing a quick comparison, we notice that Faze 9.2 price is 4.96% lower than the average cost of a Crosscountry bike.
Faze 9.2 components
Fork
The RockShox 30 Silver TK is included from the factory. It has a travel distance of 100mm. Bike forks are good shock absorbers and provide a smooth ride and a great experience. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Fox Float CTD Evolution, with a travel distance of 100mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels
The wheels on Faze 9.2 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
When you want to stop the bike in time, the brakes are vital. The Faze 9.2 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
