Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Manitou
-
Groupset GX -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Frame, 100mm Travel, tapered headtube, boost axle spacing, ISCG05 mount
Suspension Fork
Manitou J-Unit 20", Expert Air,Alloy Steerer, 120mm Travel
Rear Shock
Fox Performance FLOAT 3 Position, SV/EVOL, custom light tune
Drivetrain
Rear Derailleur
SRAM GX Short Cage
Shift Levers
SRAM GX Trigger 10 speed
Cassette
Sunrace MS1 11-36T
Crank
Samox Two Piece, 140mm
Chain
KMC X10
Pedals
SDG Composite Jr Flat
Wheels
Front Hub
Sun Ringle Duroc 30 Kids wheelset, 15x110mm
Rear Hub
Sun Ringle Duroc 30 Kids wheelset, 12x148mm Boost
Rims
Sun Ringle Duroc 30 Kids tubeless ready
Tires
Vee Rubber Crown Gem or Schwalbe Smart Sam 20x2.25", Skinwall
Brakes
Brakes
Shimano BR-MT500 hydraulic, 160mm
Cockpit
Stem
35mm reach MTB
Handlebar
SDG Kids Alloy, 640mm, 25mm rise, 31.8mm bore
Grips
SDG Jr
Headset
FSA #57 E
Seat
Saddle
SDG Fly JR
Seatpost
JD TransX Light Action Dropper, 80mm,1x lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 585 mm |
| Rake | 48 mm |
| Trail | 83 mm |
| Stack | 434 mm |
| Reach | 311 mm |
| Top Tube Length | 430 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 64 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 346 mm |
| Wheelbase | 931 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
About this model
Fluid FS 1 20 is a Norco Fluid Fs model. Norco released 111 bikes variations of this model so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Norco Fluid FS 3 29 2021 is the most economical model, with a starting price of 2249$. Norco Fluid FS 1 27.5 2021 on the other hand costs 3399$, and is the most expensive model.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Mountain bikes average price
Our math shows that the average cost of a dependable Mountain bike is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2021, its price was 3199$. Comparing the average cost of a Mountain bike to this one, you will see that Fluid FS 1 20 price is 419.32% higher.
Overview of components
Fork
The Fluid FS 1 20 comes factory-installed with the Manitou fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
Fluid FS 1 20 has an aluminum fork, which doesn’t add too much extra weight to the bike. However, it is not so stiff as steel or carbon forks are.
Rear Shock
As for the rear shock, this bike has the Fox Performance FLOAT 3 Position model, with a travel of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In conclusion, to increase your riding experience, get a bike with a rear shock if possible.
Wheels size
As for the wheels, Norco Fluid FS 1 20 2021, has a 20″ aluminum model. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fluid FS 1 20 has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Norco Fluid FS 1 20 2021 is available in one size only. In conclusion, make sure it fits you, or look for another model.
Dropper post
A dropper post is included with the Fluid FS 1 20. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
