Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 24" -
Travel Front 145mm -
Travel Rear 120mm -
Fork Manitou
-
Groupset NX, SX Eagle -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
24"
128cm - 142cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Frame, 120mm Travel, tapered headtube, boost axle spacing, ISCG05 mount
Suspension Fork
Manitou J-Unit 24", Expert Air, Alloy Steerer, 145mm Travel
Rear Shock
Fox Performance FLOAT 3-position, SV/EVOL, custom light tune
Drivetrain
Shift Levers
SRAM NX 11 speed
Cassette
SRAM PG-1130 11-42T
Crank
SRAM SX Eagle 155mm, 30T
Bottom Bracket
SRAM PowerSpline
Chain
SRAM PC-1110
Pedals
SDG Composite Jr Flat
Wheels
Front Hub
Sun Ringle Duroc 30 Kids wheelset, 15x110mm Boost
Rims
Sun Ringle Duroc 30 Kids tubeless ready
Tires
Maxxis Minion DHF Folding Bead EXO / TR 24x2.40”
Brakes
Brakes
Shimano BR-MT500 hydraulic, 180mm
Cockpit
Stem
35mm reach MTB
Handlebar
SDG Kids Alloy, 640mm, 25mm rise, 31.8mm bore
Grips
SDG Jr
Headset
FSA #57 E
Seat
Saddle
SDG Fly JR
Seatpost
JD TransX Light Action Dropper, 100mm,1x lever
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 24" |
|---|---|
| Stack Reach Ratio | 1.51 mm |
| Bottom Bracket Height | 305 mm |
| Front Center | 645 mm |
| Rake | 40 mm |
| Trail | 106 mm |
| Stack | 538 mm |
| Reach | 357 mm |
| Top Tube Length | 499 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 305 mm |
| Head Tube Angle | 64.5 ° |
| Head Tube Length | 100 mm |
| Chainstay Length | 414 mm |
| Wheelbase | 1059 mm |
| Bottom Bracket Drop | 5 mm |
| Standover Height | 576 mm |
| Wheels | 24" |
| Rider Min Height | 128 cm |
| Rider Max Height | 142 cm |
Model Overview
Fluid FS 1 24 is part of the Norco Fluid Fs model. There are 111 bikes that carry this model name. Take a sneak peek at all Norco Fluid Fs bikes models from 2021, by clicking here.
Model range prices
Norco Fluid FS 3 29 2021 is the most affordable bike of this model and has a price of 2249$. On the other hand, Norco Fluid FS 1 27.5 2021, is the most expensive and costs 3399$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Mountain bikes average price
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, even though the average price of a Mountain bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 3399$. If we compare this with the average Mountain bike cost we notice that the price is 451.79% more expensive.
Overview of components
Fork
The Fluid FS 1 24 comes factory-installed with the Manitou fork. This has a travel range of 145mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Fork material
The fork on this bike is made out of aluminum, so there won’t be much extra weight added to the bike. However, they are not so stiff as carbon forks are.
Rear Shock
The shock that’s installed on this bike is Fox Performance FLOAT 3-position, with a travel distance of 120mm. Rear shocks improve riding comfort and give you greater control over all terrains. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
The Fluid FS 1 24 2021 bike is equipped with 24″ aluminum wheels when leaving the factory. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fluid FS 1 24 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Norco Fluid FS 1 24 2021 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
Dropper post
The Norco model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
