Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Travel Front 120mm -
Travel Rear 100mm -
Fork Manitou
-
Groupset GX -
Suspension Full -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
20"
115cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Aluminum, 100mm Travel, tapered headtube, boost axle spacing, ISCG05 mount
Suspension Fork
Manitou J-Unit 20", TS Air, Alloy Steerer 120mm Travel
Rear Shock
X-Fusion 02 Pro R, custom light tune
Drivetrain
Rear Derailleur
SRAM GX Short Cage
Shift Levers
SRAM GX Trigger 10 speed
Cassette
Sunrace MS1 11-36T
Crank
Samox AM38J 3 piece 140mm, narrow/wide 30T
Bottom Bracket
square taper
Chain
KMC X10
Pedals
Jr flat resin, metal pins
Wheels
Front Hub
Alloy 6 Bolt Disc, Boost 15x110
Rear Hub
Alloy 12x148mm Boost
Rims
Alloy Double Wall Disc
Tires
Vee Rubber Crown Gem 20x2.25", Skinwall
Brakes
Brakes
Tektro HD-M276 Hydraulic, Jr lever, 160mm
Cockpit
Stem
35mm reach MTB
Handlebar
Alloy, 620mm, 15mm Rise
Grips
Norco Jr 92mm, lock on
Headset
FSA #57 E
Seat
Saddle
Norco Jr. MTB Saddle
Seatpost
Norco alloy post with micro adjust head
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 20" |
|---|---|
| Stack Reach Ratio | 1.4 mm |
| Bottom Bracket Height | 270 mm |
| Front Center | 285 mm |
| Rake | 40 mm |
| Trail | 83 mm |
| Stack | 434 mm |
| Reach | 311 mm |
| Top Tube Length | 430 mm |
| Seat Tube Angle | 75 ° |
| Seat Tube Length | 255 mm |
| Head Tube Angle | 64 ° |
| Head Tube Length | 90 mm |
| Chainstay Length | 346 mm |
| Wheelbase | 631 mm |
| Bottom Bracket Drop | 10 mm |
| Standover Height | 491 mm |
| Wheels | 20" |
| Rider Min Height | 115 cm |
| Rider Max Height | 129 cm |
Model Overview
Fluid FS 2 20 completes the Norco Fluid Fs model. 111 bikes variations carry this model name so far. Take a sneak peek at all Norco Fluid Fs bikes models from 2021, by clicking here.
Model range prices
Norco Fluid FS 3 29 2021 is the most affordable bike of this model and has a price of 2249$. On the other hand, Norco Fluid FS 1 27.5 2021, is the most expensive and costs 3399$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Mountain bikes
According to our calculations, the average cost of a Mountain bike that is reliable is 616$. However, this doesn’t mean that if you spend less money on a Mountain bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 2299$. Doing a quick comparison, we notice that Fluid FS 2 20 price is 273.21% more expensive than the average cost of a Mountain bike.
Fluid FS 2 20 components
Fork
The fork installed on this bike is the Manitou model. The travel on this model is 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Fork material
When it comes to the fork, this bike has an aluminum one, which is a lighter material. However, it is not as tough, nor durable as steel is.
Rear Shock
The Fluid FS 2 20 has a rear shock with a travel of 100mm. The model X-Fusion 02 Pro R is the one installed in this bike. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Norco Fluid FS 2 20 2021, has a 20″ aluminum model. This wheel size is used on bike models like BMX, children, or folding bikes. In conclusion, they are great for flat ground or very easy trails.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike has one size only, so it might not fit you. In conclusion, make sure it fits you, or look for another model.
