Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 130mm -
Travel Rear 120mm -
Fork RockShox 35 Silver
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
146cm - 157cm
SM
154cm - 166cm
MD
163cm - 174cm
MD
172cm - 181cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 Alloy Trail, 120mm Travel, 27.5" and 29" Options
Suspension Fork
RockShox 35 Silver R, 130mm Travel, 46mm Offset (27.5), 51mm Offset (29)
Rear Shock
Rockshox Deluxe Select, 190x42.5mm (27.5), 190x45mm (29)
Drivetrain
Rear Derailleur
Shimano Deore RD-M6100
Shift Levers
Shimano Deore SL-M6100-R I-Spec EV
Cassette
Shimano Deore CS-M6100-12, 10-51T, 12 Speed
Crank
Shimano Deore FC-MT510-1, 32T, 170mm (XXS - S), 175mm (M - XL)
Bottom Bracket
Shimano Cartridge Bearing, BSA Threaded
Chain
Shimano Deore CN-M6100
Pedals
VP Nylon Flat
Wheels
Front Hub
Shimano HB-MT400-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Flow D, 32H
Tires
Maxxis Dissector 2.4" 3C/EXO/TR
Brakes
Brakes
Shimano BR-MT420, 4 Piston, Organic Pads
Brake Levers
Shimano BR-MT420
Disk Rotors
Shimano SMRT54, 180mm
Cockpit
Stem
6061 Alloy, 50mm Length, 35mm Clamp
Handlebar
TranzX 6061 Butted Alloy, 780mm, 20mm Rise
Grips
VP Lock-On
Headset
Sealed Bearing, Tapered
Seat
Saddle
Norco XC
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (s), 150mm (M), 170mm (L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | MD | LG | XL |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.4 mm | 1.33 mm | 1.37 mm | 1.3 mm | 1.24 mm |
| Bottom Bracket Height | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm | 342 mm |
| Front Center | 671 mm | 705 mm | 739 mm | 742 mm | 777 mm | 810 mm |
| Rake | 42 mm | 42 mm | 42 mm | 51 mm | 51 mm | 51 mm |
| Trail | 114 mm | 114 mm | 114 mm | 109 mm | 109 mm | 109 mm |
| Stack | 572 mm | 581 mm | 591 mm | 607 mm | 616 mm | 625 mm |
| Reach | 384 mm | 414 mm | 444 mm | 444 mm | 474 mm | 504 mm |
| Top Tube Length | 526 mm | 558 mm | 590 mm | 594 mm | 627 mm | 659 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 370 mm | 390 mm | 420 mm | 420 mm | 450 mm | 490 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66.5 ° | 66.5 ° | 66.5 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 433 mm | 433 mm | 433 mm |
| Wheelbase | 1105 mm | 1139 mm | 1173 mm | 1173 mm | 1208 mm | 1241 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 18 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 644 mm | 658 mm | 668 mm | 686 mm | 698 mm | 708 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 146 cm | 154 cm | 163 cm | 172 cm | 172 cm | 181 cm |
| Rider Max Height | 157 cm | 166 cm | 174 cm | 181 cm | 184 cm | 191 cm |
About this model
Fluid FS 2 27.5 is part of the Norco Fluid Fs model. 111 bikes variations carry this model name so far. Take a sneak peek at all Norco Fluid Fs bikes models from 2021, by clicking here.
Model range prices
Norco Fluid FS 3 29 2021 is the most economical model, with a starting price of 2249$. Norco Fluid FS 1 27.5 2021 on the other hand costs 3399$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2021 for 2699$. Comparing this to the average Trail bike price, we see that the price is 2.33% lower.
Overview of components
Fork
Norco Fluid FS 2 27.5 2021 bike is equipped with the RockShox 35 Silver fork, and has 130mm travel. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
Norco Fluid FS 2 27.5 bike has the Rockshox Deluxe Select model installed, and has a travel of 120mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
The Fluid FS 2 27.5 2021 bike is equipped with 27.5″ aluminum wheels when leaving the factory. These wheels will provide you with more control over the bike. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Norco Fluid FS 2 27.5 is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Sizes
Fluid FS 2 27.5 comes in 6 sizes, that range from 146 cm – 191 cm (4.79 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Norco model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
