Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork RockShox Recon Gold RL
-
Groupset X01 -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC High-Mod 29
Suspension Fork
RockShox Recon Gold TK SoloAir 15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM X01 Alloy
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM X01 10/42
Crank
SRAM X01 34T
Bottom Bracket
SRAM X01 PF30
Chain
SRAM XX1
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Kore Durox 15mm
Rear Hub
Kore Durox 142x12
Rims
Stans ZTR Rapid 29
Tires
Schwalbe Racing Ralph 2.1 x 29
Brakes
Brakes
Avid Elixir 7 Trail 160mm/ Connectamajig
Brake Levers
Avid Elixir 7 Trail
Disk Rotors
N/A
Cockpit
Stem
Norco SL Alloy Stem
Handlebar
Norco Lite 700mm Flat Bar
Grips
Norco SL Silicon
Headset
FSA No.42ACB w/8mm Alloy spacer
Seat
Saddle
Prologo Zero
Seatpost
Norco SL Alloy Post 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9.1 HT completes the Norco Revolver model. There are 148 bikes that carry this model name. You can easily view all of the Norco Revolver bikes models from 2014, here.
Model range prices
Norco Revolver 7.2 HT 2014 is the most economical model, with a starting price of 1955$. Norco Revolver 7 LE HT 2014 on the other hand costs 5535$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even though the average price of a Crosscountry bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
At the moment of the release date, Norco Revolver 9.1 HT price was 3615$. If we compare this with the average Crosscountry bike cost we notice that the price is 89.76% higher.
Overview of components
Fork
Norco Revolver 9.1 HT 2014 bike is equipped with the RockShox Recon Gold RL fork, and has 100mm travel. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Wheels size
When leaving the production line, the Revolver 9.1 HT model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, these wheels are not ideal for smaller people.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver 9.1 HT comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
