Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Wheels 29" -
Travel Front 100mm -
Fork RockShox SID
-
Groupset XX1 -
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Norco XC High-Mod 29
Suspension Fork
RockShox Sid XX Tapered 15mm
Rear Shock
N/A
Drivetrain
Rear Derailleur
SRAM XX1
Front Derailleur
N/A
Shift Levers
N/A
Cassette
SRAM XX1 10/42
Crank
SRAM XX1 34T
Bottom Bracket
SRAM XX1 PF30
Chain
SRAM XX1
Chain Tensioner
N/A
Pedals
N/A
Wheels
Front Hub
Kore Durox 15mm
Rear Hub
Kore Durox 142x12
Rims
Stans ZTR Crest 29
Tires
Schwalbe Rocket Ron TLR 2.1 x 29
Brakes
Brakes
SRAM X0 160mm/Connectamajig
Brake Levers
SRAM XO
Disk Rotors
N/A
Cockpit
Stem
Easton EA70 Alloy
Handlebar
Easton EC70 Carbon Lo Riser 720mm
Grips
Norco SL Silicon
Headset
FSA No.42ACB w/8mm Alloy spacer
Seat
Saddle
Prologo Zero II TiRox
Seatpost
Easton EC90 Carbon 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.56 mm | 1.47 mm | 1.44 mm | 1.41 mm |
| Bottom Bracket Height | 303 mm | 303 mm | 303 mm | 303 mm |
| Front Center | 638.1 mm | 659.4 mm | 681.4 mm | 704.1 mm |
| Rake | 46 mm | 46 mm | 46 mm | 46 mm |
| Trail | 86 mm | 84 mm | 82 mm | 80 mm |
| Stack | 616.1 mm | 617.2 mm | 632.4 mm | 647.7 mm |
| Reach | 394.9 mm | 418.7 mm | 438.2 mm | 458.5 mm |
| Top Tube Length | 573 mm | 600 mm | 627 mm | 655 mm |
| Seat Tube Angle | 73.75 ° | 73.5 ° | 73.25 ° | 73 ° |
| Seat Tube Length | 405 mm | 445 mm | 483 mm | 533 mm |
| Head Tube Angle | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° |
| Head Tube Length | 90 mm | 90 mm | 105 mm | 120 mm |
| Chainstay Length | 440 mm | 442 mm | 445 mm | 447 mm |
| Wheelbase | 1069 mm | 1093 mm | 1118 mm | 1143 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 750 mm | 790 mm | 817 mm | 846 mm |
| Front Travel | 100 mm | 100 mm | 100 mm | 100 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Revolver 9 LE HT is part of the Norco Revolver model. There are 148 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Model range prices
Norco Revolver 7.2 HT 2014 is the most affordable bike of this model and has a price of 1955$. On the other hand, Norco Revolver 7 LE HT 2014, is the most expensive and costs 5535$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Norco released this model in 2014, its price was 5535$. Doing a quick comparison, we notice that Revolver 9 LE HT price is 190.55% more expensive than the average cost of a Crosscountry bike.
Revolver 9 LE HT components
Fork
The Revolver 9 LE HT comes factory-installed with the RockShox SID fork. This has a travel range of 100mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels
When leaving the production line, the Revolver 9 LE HT model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Revolver 9 LE HT has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Revolver 9 LE HT comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, it won’t be difficult to find the right one for you.
