Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Ultimate
-
Groupset XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon XC Race, Ride Aligned™
Suspension Fork
RockShox SID Ultimate, 120mm, 44mm Offset
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano XT Sl-M8100 I-Spec EV
Cassette
Shimano XT CS-M8100, 10-51T, 12 Speed
Crank
Praxxis Girder Carbon M30, 32T, 170mm (S), 175mm (M, L, XL)
Bottom Bracket
Praxxis M30 BB92
Chain
Shimano XT CN-M8100
Wheels
Front Hub
Shimano XT HB-8110-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano XT FH-8110-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stans Arch S1 29" 32H
Tires
Schwalbe Nobby Nic Evo, 2.35", Super Terrain, TLE
Brakes
Brakes
Shimano XT BR-M8020, Metallic Pads, Ice Tech, 4 Piston
Brake Levers
Shimano XT BR-M8020
Disk Rotors
Shimano XT MT800, 180mm
Cockpit
Stem
6061 Alloy, 60mm Length, 35mm Clamp
Handlebar
One Up Carbon 800mm, 20mm Rise
Grips
Ergon GA20 Lock-On
Headset
FSA Internal
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (S), 150mm (M, L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.28 mm | 1.22 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 706 mm | 736 mm | 770 mm | 803 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 596 mm | 596 mm | 605 mm | 615 mm |
| Reach | 413 mm | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 572 mm | 602 mm | 635 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.8 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1111 mm | 1145 mm | 1182 mm | 1219 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 666 mm | 683 mm | 718 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Revolver HT 1 120 is part of the Norco Revolver model. 148 bikes variations carry this model name so far. Check out the entire range from 2021 of this model, by clicking this link.
Model range prices
Norco Revolver HT 3 120 2021 is the most economical model, with a starting price of 2799$. Norco Revolver FS AXS 120 2021 on the other hand costs 10999$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Norco released this model in 2021, its price was 4899$. Doing a quick comparison, we notice that Revolver HT 1 120 price is 77.37% higher than the average cost of a Trail bike.
Overview of components
Fork
The Revolver HT 1 120 comes factory-installed with the RockShox SID Ultimate fork. This has a travel range of 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When leaving the production line, the Revolver HT 1 120 model has 29″ aluminum wheels. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Revolver HT 1 120 comes with Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, it won’t take much to find one that’s right for you.
Dropper post
Norco Revolver HT 1 120 includes a dropper post. If used correctly, a dropper post gives you more faith, maneuverability, and greater control over your bike.
