Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Fork RockShox SID Select
-
Groupset XT, SLX -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 166cm
MD
163cm - 175cm
LG
172cm - 184cm
XL
181cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon XC Race, Ride Aligned™
Suspension Fork
RockShox SID Select, 120mm, 51mm Offset
Drivetrain
Rear Derailleur
Shimano XT RD-M8100
Shift Levers
Shimano SLX SL-M7100-IR I-Spec EV
Cassette
Shimano SLX, 10-51T, 12 Speed
Crank
Shimano FC-MT6100, 32T, 170mm (S), 175mm (M, L, XL)
Bottom Bracket
Shimano BB-MT500 PF92
Chain
Shimano Deore
Wheels
Front Hub
Shimano HB-MT400-B, 15x110mm Boost, Center Lock
Rear Hub
Shimano FH-MT510-B, 12x148mm Boost, Micro Spline, Center Lock
Rims
Stan's Arch S1 29" 32H
Tires
Front: Schwalbe Nobby Nic Evo, 2.35", Super Terrain, TLE, Rear: Schwalbe Nobby Nic Evo, 2.35", Super Terrain, TLE
Brakes
Brakes
Front: Shimano Deore BR-MT420, Matallic Pads, 4 Piston, Rear: Shimano Deore BR-MT420, Matallic Pads, 4 Piston
Brake Levers
Shimano BR-MT420
Cockpit
Stem
Norco SL Alloy Stem, 60mm Length, 31.8mm Clamp
Handlebar
Butted Alloy Lite, 760mm, 15mm Rise
Grips
Ergon GA20 Lock-On
Headset
FSA Internal
Seat
Saddle
Fizik Alpaca Terra, Wingflex
Seatpost
X-Fusion Manic Dropper, 31.6mm, 125mm (S), 150mm (M, L, XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.35 mm | 1.28 mm | 1.22 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 706 mm | 736 mm | 770 mm | 803 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 97 mm | 97 mm | 97 mm | 97 mm |
| Stack | 596 mm | 596 mm | 605 mm | 615 mm |
| Reach | 413 mm | 443 mm | 473 mm | 503 mm |
| Top Tube Length | 572 mm | 602 mm | 635 mm | 667 mm |
| Seat Tube Angle | 75.3 ° | 75.3 ° | 75.3 ° | 75.3 ° |
| Seat Tube Length | 425 mm | 440 mm | 485 mm | 510 mm |
| Head Tube Angle | 67.8 ° | 67.8 ° | 67.8 ° | 67.8 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 110 mm |
| Chainstay Length | 411 mm | 414 mm | 417 mm | 421 mm |
| Wheelbase | 1111 mm | 1145 mm | 1182 mm | 1219 mm |
| Bottom Bracket Drop | 54 mm | 54 mm | 54 mm | 54 mm |
| Standover Height | 666 mm | 683 mm | 718 mm | 741 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 163 cm | 172 cm | 181 cm |
| Rider Max Height | 166 cm | 175 cm | 184 cm | 191 cm |
Model Overview
Revolver HT 2 120 is a Norco Revolver model. Norco launched 148 bikes of this model so far. You can easily view all of the Norco Revolver bikes models from 2022, here.
Model range prices
Norco Revolver HT 3 120 2022 is the most economical model, with a starting price of 2799$. Norco Revolver FS AXS 120 2022 on the other hand costs 8699$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Trail bikes average price
If you want to purchase a solid Trail bike, it is important to know that the average cost is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Norco Revolver HT 2 120 price was 3799$. Doing a quick comparison, we notice that Revolver HT 2 120 price is 37.55% higher than the average cost of a Trail bike.
Overview of components
Fork
The Revolver HT 2 120 comes factory-installed with the RockShox SID Select fork. This has a travel range of 120mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels
When leaving the production line, the Revolver HT 2 120 model has 29″ aluminum wheels. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Revolver HT 2 120 has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 154 cm – 191 cm (5.05 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
Every bike should have a dropper post, and this one does. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
