Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset GRX 400, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
49cm
154cm - 165cm
52cm
162cm - 172cm
55cm
169cm - 180cm
58cm
177cm - 188cm
61cm
185cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Butted Aluminum, Smooth Welds
Suspension Fork
Full Carbon, Through Axle
Drivetrain
Rear Derailleur
Shimano GRX RD-RX400 Shadow RD+
Front Derailleur
Shimano Tiagra FD-4700
Shift Levers
Shimano Tiagra ST-4700
Cassette
Shimano CS-HG50, 11-36T, 10 Speed
Crank
FSA Vera Pro Adventure, 48/32, 170mm (49, 52), 172.5mm (55, 58), 175mm (61)
Bottom Bracket
FSA Square Taper
Chain
KMC X10
Chain Tensioner
-
Pedals
City Resin
Wheels
Front Hub
12x100mm Through Axle, 6 Bolt
Rear Hub
12x142mm Through Axle, HG, 6 Bolt
Rims
Alloy Pinned, 28H, 21mm ID
Tires
Front: Fast Rolling Gravel 700x35c, Rear: Fast Rolling Gravel 700x35c
Brakes
Brakes
Front: Tektro MD-C550 Dual Piston Mechanical Disc, Rear: Tektro MD-C550 Dual Piston Mechanical Disc
Brake Levers
Shimano Tiagra ST-4700
Cockpit
Stem
Norco SL Aluminum, 31.8mm Clamp, 70mm (49), 80mm (52), 90mm (55), 100mm (58), 110mm (61)
Handlebar
Norco Flare Aluminum, 16 Degree Flare, 40cm (49), 42cm (52), 44cm (55), 46cm (58, 61)
Grips
Griptacular Shockproof Tape
Headset
Sealed Cartridge Bearing
Seat
Saddle
Selle Royal Gravel with Cutout
Seatpost
Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 55cm | 58cm | 61cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.44 mm | 1.47 mm | 1.49 mm | 1.52 mm |
| Bottom Bracket Height | 268.5 mm | 268.5 mm | 271 mm | 273.5 mm | 273.5 mm |
| Front Center | 596 mm | 606 mm | 615 mm | 624 mm | 633 mm |
| Rake | 50 mm | 50 mm | 50 mm | 50 mm | 50 mm |
| Trail | 70 mm | 68 mm | 66 mm | 65 mm | 63 mm |
| Stack | 533 mm | 553 mm | 571 mm | 588 mm | 608 mm |
| Reach | 379 mm | 384 mm | 389 mm | 394 mm | 399 mm |
| Top Tube Length | 537 mm | 551 mm | 564 mm | 577 mm | 591 mm |
| Seat Tube Angle | 73.5 ° | 73.25 ° | 73 ° | 72.75 ° | 72.5 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 580 mm |
| Head Tube Angle | 70.75 ° | 71 ° | 71.25 ° | 71.5 ° | 71.75 ° |
| Head Tube Length | 100 mm | 120 mm | 140 mm | 160 mm | 180 mm |
| Chainstay Length | 414 mm | 416 mm | 419 mm | 421 mm | 424 mm |
| Wheelbase | 996 mm | 1009 mm | 1021 mm | 1033 mm | 1045 mm |
| Bottom Bracket Drop | 82 mm | 82 mm | 80 mm | 77 mm | 77 mm |
| Standover Height | 664 mm | 692 mm | 722 mm | 752 mm | 789 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 154 cm | 162 cm | 169 cm | 177 cm | 185 cm |
| Rider Max Height | 165 cm | 172 cm | 180 cm | 188 cm | 194 cm |
About this model
Search A1 completes the Norco Search model. Norco released 121 bikes variations of this model so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Norco Search XR Flat Bar 2023 is the most economical model, with a starting price of 1349$. Norco Search XR S1 700c 2023 on the other hand costs 3299$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel bikes average price
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Norco Search A1 price was 1649$. If we compare this with the average Gravel bike cost we notice that the price is 49.3% smaller.
Overview of components
Fork material
The fork is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels
When it comes to wheels, the Search A1 bike is equipped with the 700c aluminum model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
For your safety, it is important to have quality breaks on your bike. Norco Search A1 has Mechanical Disc brakes installed. They deliver good performance and cost less than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 154 cm – 194 cm (5.05 ft – 6.36 ft). In short, it won’t be difficult to find the right one for you.
